Stator/Rotor для Mercury - 8 (BODENSEE) 4-STROKE (International) 0H017100 THRU 0H017265

  • №
    Артикул
    Название
  • 1
    825663 SHAFT
    SHAFT
  • 2
    825662T COVER, Flywheel
    COVER, Flywheel
  • 3
    10-825510 SCREW
    SCREW
  • 4
    825665 COLLAR
    COLLAR
  • 5
    25-11416T GROMMET
    GROMMET
  • 6
    11-81770M NUT
    NUT
  • 7
    12-81814M WASHER
    WASHER
  • 8
    825658 ROTOR
    ROTOR
  • 9
    10-827029 BOLT
    BOLT
  • 10
    827399 STATOR
    STATOR
  • 11
    825660T MAGNETO BASE
    MAGNETO BASE
  • 12
    10-827027 SCREW
    SCREW
  • 13
    10-827026 SCREW
    SCREW
  • 14
    17-825010 PIN, Dowel
    PIN, Dowel
  • 15
    28-8M0057164 KEY
    KEY
  • 16
    825661 PULSER
    PULSER
  • 17
    10-82104510 SCREW, (M5 x 10)
    SCREW, (M5 x 10)
  • 18
    NSS NOT SOLD SEPARATE, Decal-Emergency Start Procdure
    NOT SOLD SEPARATE, Decal-Emergency Start Procdure
  • 19
    NSS NOT SOLD SEPARATE, Decal-Flywheel Cover
    NOT SOLD SEPARATE, Decal-Flywheel Cover
  • 20
    37-855920 DECAL, EPA Label Information, Export
    DECAL, EPA Label Information, Export
  • 21
    NSS NOT SOLD SEPARATE, Decal-Servicing Referral
    NOT SOLD SEPARATE, Decal-Servicing Referral
  • 22
    NSS NOT SOLD SEPARATE, Decal-Warning-Neutral
    NOT SOLD SEPARATE, Decal-Warning-Neutral
