CLUTCH для Ktm 50 SX - 2017 года выпуска

  • №
    Артикул
    Название
  • 1
    45232100144 AXIAL CLUTCH ASSEMBLY
    AXIAL CLUTCH ASSEMBLY
  • 2
    45232101000 CLUTCH BASKET
    CLUTCH BASKET
  • 3
    45232139044 BALL CAGE ASSEMBLY
    BALL CAGE ASSEMBLY
  • 4
    45232110033 CLUTCH DISC KIT
    CLUTCH DISC KIT
  • 5
    0035080206S AH-COLLAR SCREW M8X20 ISA45
    AH-COLLAR SCREW M8X20 ISA45
  • 6
    0401110000 BALL D=11MM
    BALL D=11MM
  • 7
    45232103000 PRESSURE PLATE
    PRESSURE PLATE
  • 8
    0991060166S FL.HEAD SCR.DIN7991-M6X16 10.9
    FL.HEAD SCR.DIN7991-M6X16 10.9
  • 9
    45232105000 CLUTCH SPRING 15,9MM
    CLUTCH SPRING 15,9MM
  • 9
    45232105100 CLUTCH SPRINGS 15.9MM HARD
    CLUTCH SPRINGS 15.9MM HARD
  • 10
    0340084234 WASHER DIN 6340 8,4X23X4
    WASHER DIN 6340 8,4X23X4
  • 11
    45232107244 FIT BOLT WITH DRIVE PLATE
    FIT BOLT WITH DRIVE PLATE
  • 12
    75034050000 STOP DISK 14X30X1,5 STEEL
    STOP DISK 14X30X1,5 STEEL
  • 13
    0402182412 NEEDLE BEARING 18X24X12A
    NEEDLE BEARING 18X24X12A
  • 14
    45232013000 INNER RING WITH COLLAR
    INNER RING WITH COLLAR
  • 15
    09910601661S FL.HEAD SCR.DIN7991-M6X16 10.9
    FL.HEAD SCR.DIN7991-M6X16 10.9
