EVAPORATIVE CANISTER для Ktm 1290 ADVENTURE - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    59415001100 EVAPORATIVE CANISTER
    EVAPORATIVE CANISTER
  • 2
    75015001100 EVAPORATIVE CANISTER
    EVAPORATIVE CANISTER
  • 3
    61115015000 VALVE FOR CARBON CANISTER
    VALVE FOR CARBON CANISTER
  • 4
    61115016000 FITTING PIECE NQV2 NW7 90°
    FITTING PIECE NQV2 NW7 90°
  • 5
    76515032000 RETAINING PLATE VALVE EC
    RETAINING PLATE VALVE EC
  • 6
    59007439000 CLAMP RSGU 18/15
    CLAMP RSGU 18/15
  • 7
    0025050106 COLLAR SCREW M5X10 ISA30
    COLLAR SCREW M5X10 ISA30
  • 8
    60015022000 T -CONNECTOR TS-6
    T -CONNECTOR TS-6
  • 9
    58007017000 YDNAC CLAMP 10101 (10,4MM)
    YDNAC CLAMP 10101 (10,4MM)
  • 10
    69015019010 HOSE CONNECTION STRAIGHT
    HOSE CONNECTION STRAIGHT
  • 11
    61315022000 PREFORMED HOSE 6X10 FPM
    PREFORMED HOSE 6X10 FPM
  • 12
    78015019000 HOSE EPA D=6/10 L=2000MM
    HOSE EPA D=6/10 L=2000MM
  • 13
    60415020000 PREFORMED HOSE
    PREFORMED HOSE
  • 14
    0081050121 SCREW FOR PLASTIC K50X12 T20
    SCREW FOR PLASTIC K50X12 T20
  • 15
    60415002000 BRACKET EVAP CANISTER
    BRACKET EVAP CANISTER
  • 16
    69008021080 RANGE CHANGE METAL NUT M5
    RANGE CHANGE METAL NUT M5
