ENGINE CASE для Ktm 250 XC-W - 2013 года выпуска

  • №
    Артикул
    Название
  • 1
    55130000333 ENGINE CASE CPL.
    ENGINE CASE CPL.
  • 15
    0025060126 HH COLLAR SCREW M6X12 TX30
    HH COLLAR SCREW M6X12 TX30
  • 16
    50232050001 STEEL WASHER 6,4X17X3
    STEEL WASHER 6,4X17X3
  • 18
    59033018000 BUSHING PIN
    BUSHING PIN
  • 19
    0912060123 AH SCREW DIN0912-M 6X12
    AH SCREW DIN0912-M 6X12
  • 20
    0912060404 AH SCREW DIN0912-M 6X40 A2
    AH SCREW DIN0912-M 6X40 A2
  • 26
    54830024000 CLUTCH COVER GASKET
    CLUTCH COVER GASKET
  • 27
    54630027000 DOWEL BUSHING 13,8X11X12
    DOWEL BUSHING 13,8X11X12
  • 28
    54830027000 DOWEL 21X12
    DOWEL 21X12
  • 39
    54830039000 ENGINE CASE GASKET
    ENGINE CASE GASKET
  • 49
    54634049000 RETAINING PLATE
    RETAINING PLATE
  • 60
    0025060406 HH COLLAR SCREW M6X40 TX30
    HH COLLAR SCREW M6X40 TX30
  • 63
    0025060556 HH COLLAR SCREW M6X55 TX30
    HH COLLAR SCREW M6X55 TX30
  • 64
    0025060606 HH COLLAR SCREW M6X60 TX30
    HH COLLAR SCREW M6X60 TX30
  • 99
    55130099000 GASKET SET
    GASKET SET
