SHOCK ABSORBER для Ktm 690 DUKE (ORANGE) - 2010 года выпуска

  • №
    Артикул
    Название
  • 1*
    15187J0901 MONOSHOCK 690 DUKE
    MONOSHOCK 690 DUKE
  • 2
    75004016000 SCREW M 10 L=53MM
    SCREW M 10 L=53MM
  • 3
    50180213S9 DCC-COMPR.DAMP.CONTROL CPL.
    DCC-COMPR.DAMP.CONTROL CPL.
  • 4
    91110012S SPRING 185MM 70N/MM (61)
    SPRING 185MM 70N/MM (61)
  • 5
    46180766 COUNTERNUT
    COUNTERNUT
  • 6
    46180855 ADJUSTING NUT
    ADJUSTING NUT
  • 7
    46180396 SPRING RETAINER H=15 D=28
    SPRING RETAINER H=15 D=28
  • 8
    R15002 REPAIR-KIT GASKET
    REPAIR-KIT GASKET
  • 9
    R15006 REPAIR KIT BEARINGS
    REPAIR KIT BEARINGS
  • 10
    50180342S1 SHOCK ABSORBER FLUID 5 LT
    SHOCK ABSORBER FLUID 5 LT
  • 11*
    46180654S9 SHOCK ABS. BOTTOM CPL. DUKE
    SHOCK ABS. BOTTOM CPL. DUKE
  • 12
    46180807S1 MONOSHOCK TOP PART CPL. DUKE
    MONOSHOCK TOP PART CPL. DUKE
  • 13
    50180095 BLEED PLUG R 1/8
    BLEED PLUG R 1/8
  • 14
    46810361 PISTON RING
    PISTON RING
  • 15
    46810010 CIRCLIP 49X1,5
    CIRCLIP 49X1,5
  • 20*
    52000087 STICKER WP MONOSHOCK
    STICKER WP MONOSHOCK
