IGNITION SYSTEM для Ktm 450 XC-W - 2010 года выпуска

  • №
    Артикул
    Название
  • 1
    7803000210015 IGNITION COVER
    IGNITION COVER
  • 2
    58030020100 PLUG CPL. M24X3
    PLUG CPL. M24X3
  • 3
    0770191015 O-RING 19,00X3,00 NBR
    O-RING 19,00X3,00 NBR
  • 4
    78030040000 GASKET IGNITION COVER
    GASKET IGNITION COVER
  • 5
    77339034000 PULSER COIL KOKUSAN "PU5165"
    PULSER COIL KOKUSAN "PU5165"
  • 6
    78039031100 CDI UNIT 450 EXC
    CDI UNIT 450 EXC
  • 7
    78030095000 OIL LEVEL GLASS 30X8
    OIL LEVEL GLASS 30X8
  • 8
    61030019050 CIRCLIP OIL LEVEL GLASS
    CIRCLIP OIL LEVEL GLASS
  • 9
    78039090000 SPARK PLUG CONNECT. AP-TRS1908
    SPARK PLUG CONNECT. AP-TRS1908
  • 10
    75039093000 SPARK PLUG M12X1,25 LKAR8AI-9
    SPARK PLUG M12X1,25 LKAR8AI-9
  • 11
    0025050166 HH COLLAR SCREW M5X16 TX30
    HH COLLAR SCREW M5X16 TX30
  • 12
    0402040980 NEEDLE ROL.DIN5402 NRB 4X9,8
    NEEDLE ROL.DIN5402 NRB 4X9,8
  • 13
    0019040106S FLAT HEAD SCREW ISA25 M4X10
    FLAT HEAD SCREW ISA25 M4X10
  • 14
    78030002010 WIRING RETAINING BRACKET
    WIRING RETAINING BRACKET
  • 15
    78039032000 WIRING HARNESS F. CDI-BOX
    WIRING HARNESS F. CDI-BOX
  • 16
    59039006000 IGNITIONCOIL KOKUSAN 4K3-A/B
    IGNITIONCOIL KOKUSAN 4K3-A/B
  • 20
    78039005000 FLYWHEEL
    FLYWHEEL
  • 21
    80039004000 STATOR HUSABERG FS/FE 04
    STATOR HUSABERG FS/FE 04
  • 22
    0137120000 SPRING WASHER DIN0137-B12
    SPRING WASHER DIN0137-B12
  • 23
    49030021000 COLLAR NUT M12X1 R/S
    COLLAR NUT M12X1 R/S
  • 25
    0888030050 WOODRUFF KEY DIN6888-3X5X13
    WOODRUFF KEY DIN6888-3X5X13
  • 35
    0023060123 COLLAR SCREW M6X12 TX
    COLLAR SCREW M6X12 TX
  • 36
    0025060166 HH COLLAR SCREW M6X16 TX30
    HH COLLAR SCREW M6X16 TX30
  • 50
    0025060256 HH COLLAR SCREW M6X25 TX30
    HH COLLAR SCREW M6X25 TX30
  • 51
    0025060406 HH COLLAR SCREW M6X40 TX30
    HH COLLAR SCREW M6X40 TX30
