MASK FENDERS для Ktm 250 XC-W - 2007 года выпуска

  • №
    Артикул
    Название
  • 1
    5480800701004 NUMBER PLATE CPL. ORANGE
    NUMBER PLATE CPL. ORANGE
  • 3
    54808019000 BRAKE HOSE GUIDE BLACK
    BRAKE HOSE GUIDE BLACK
  • 4
    0017060204 EJOT PT SCREW K60X20 ALU WS=6
    EJOT PT SCREW K60X20 ALU WS=6
  • 5
    0014060153 HH COLLAR SCREW M 6X15 WS=8
    HH COLLAR SCREW M 6X15 WS=8
  • 7
    5030801030004 FENDER FRONT WIDE ORANGE
    FENDER FRONT WIDE ORANGE
  • 9
    54808020000 SPACER BUSHING
    SPACER BUSHING
  • 11
    0014060203 HH COLLAR SCREW M 6X20 WS=8
    HH COLLAR SCREW M 6X20 WS=8
  • 12
    50308009100 FENDER BRACE BLACK
    FENDER BRACE BLACK
  • 13
    50308009050 SCREW FEND.BRACE M8X9 WS=17
    SCREW FEND.BRACE M8X9 WS=17
  • 14
    50308009051 NUT FENDER BRACE M8 WS=17
    NUT FENDER BRACE M8 WS=17
  • 20
    5480801300004 REAR PART SX ORANGE
    REAR PART SX ORANGE
  • 22
    50314057050 COLLAR NUT M12X1/WS17 H=5MM
    COLLAR NUT M12X1/WS17 H=5MM
  • 23
    54807048000 BUSHING FOR SEAT FASTENING
    BUSHING FOR SEAT FASTENING
  • 24
    0015060253 HH COLLAR SCREW M 6X25 WS=8
    HH COLLAR SCREW M 6X25 WS=8
  • 25
    50308052000 BUSH FOR SPOILER 6X11X16X5 MM
    BUSH FOR SPOILER 6X11X16X5 MM
  • 26
    0015060163 HH COLLAR SCREW M6X16 WS=8
    HH COLLAR SCREW M6X16 WS=8
