HANDLEBAR W/ CONTROLS для Ktm 50 Sr Adventure - 2005 года выпуска

  • №
    Артикул
    Название
  • 1
    45102001000 HANDLEBAR
    HANDLEBAR
  • 4
    45002010000 TWIST GRIP CPL. 50 SXR
    TWIST GRIP CPL. 50 SXR
  • 5
    45002039000 RUBBER GRIP
    RUBBER GRIP
  • 7
    45113010000 BRAKE CABLE FRONT
    BRAKE CABLE FRONT
  • 7
    45113010100 BRAKE CABLE REAR
    BRAKE CABLE REAR
  • 8
    45102091000 THROTTLE CABLE SEN.
    THROTTLE CABLE SEN.
  • 9
    50311089200 SHORT CIRCUIT BUTTON
    SHORT CIRCUIT BUTTON
  • 10
    45011089044 S.CIRCUIT BUTTON W. RIP CORD
    S.CIRCUIT BUTTON W. RIP CORD
  • 15
    44011076200 CABLE TIE 200/3,6MM BLACK
    CABLE TIE 200/3,6MM BLACK
  • 15
    44011076100 CABLE TIE 100/2,5MM SLACK
    CABLE TIE 100/2,5MM SLACK
  • 30
    45113001044 HAND BRAKE LEVER CPL. R/S
    HAND BRAKE LEVER CPL. R/S
  • 30
    46002040100 CLUTCH LEVER CPL. (HAND BRAKE LEVER L/S)
    CLUTCH LEVER CPL. (HAND BRAKE LEVER L/S)
  • 31
    45113042000 HAND BRAKE LEVER LOOSE
    HAND BRAKE LEVER LOOSE
  • 31
    46002042100 CLUTCH LEVER LOOSE (HAND BRAKE LEVER L/S)
    CLUTCH LEVER LOOSE (HAND BRAKE LEVER L/S)
  • 34
    46002048000 PLASTIC CAP FOR CLUTCH LEVER
    PLASTIC CAP FOR CLUTCH LEVER
  • 35
    46002043100 ADJUST SCREW CLUTCH LEVER
    ADJUST SCREW CLUTCH LEVER
  • 36
    0015060203 HH COLLAR SCREW M 6X20 WS=8
    HH COLLAR SCREW M 6X20 WS=8
