SWINGARM W/ CHAIN GUARD для Ktm 125 EXC - 2005 года выпуска

  • №
    Артикул
    Название
  • 2
    54804230244 SWINGARM CPL.
    SWINGARM CPL.
  • 3
    50304066100 CHAIN GUARD
    CHAIN GUARD
  • 4
    72210079000 BUCKET
    BUCKET
  • 5
    0015060103 HH COLLAR SCREW M 6X10 WS=8
    HH COLLAR SCREW M 6X10 WS=8
  • 6
    54611076100 RETAIN.CLAMP FOR BRAKE HOSE
    RETAIN.CLAMP FOR BRAKE HOSE
  • 7
    0009050103 SPECIAL SCREW M 5,0X10
    SPECIAL SCREW M 5,0X10
  • 8
    54804034000 BUCKET F. SHAFT SEAL RING
    BUCKET F. SHAFT SEAL RING
  • 9
    0760253270 SHAFT SEAL RING 25X32X7
    SHAFT SEAL RING 25X32X7
  • 10
    54804032000 BUSHING SLEEVE F. SWING ARM
    BUSHING SLEEVE F. SWING ARM
  • 11
    58033097000 NEEDLE BEARING HK 2216
    NEEDLE BEARING HK 2216
  • 12
    54603036000 STOP DISK 22,2X31,7X1
    STOP DISK 22,2X31,7X1
  • 13
    54607066100 CHAIN GUIDE REAR
    CHAIN GUIDE REAR
  • 14
    54607070144 RETAINING PLATE CPL.
    RETAINING PLATE CPL.
  • 15
    0015060163 HH COLLAR SCREW M 6X16 WS=8
    HH COLLAR SCREW M 6X16 WS=8
  • 16
    0015060503 HH COLLAR SCREW M 6X50 WS=8
    HH COLLAR SCREW M 6X50 WS=8
  • 18
    50304090044 PIVOT BEARING+BUSHES PDS
    PIVOT BEARING+BUSHES PDS
  • 19
    50329000044 TOOL BEARING MOUNTING PDS
    TOOL BEARING MOUNTING PDS
  • 20
    50304060100 CHAIN GUARD SMALL
    CHAIN GUARD SMALL
  • 21
    54607460000 CHAIN GUARD LARGE
    CHAIN GUARD LARGE
  • 22
    20012062055 HOLLOW RIVET TWO PARTS
    HOLLOW RIVET TWO PARTS
  • 23
    0985060003 SELF LOCK. NUT DIN0985-M 6
    SELF LOCK. NUT DIN0985-M 6
  • 24
    0021060003 WASHER DIN9021-A 6,4
    WASHER DIN9021-A 6,4
  • 25
    54804037000 SWINGARM BOLT M16X1,5
    SWINGARM BOLT M16X1,5
  • 26
    54804038000 SELF LOCK.NUT M16X1,5 WS=19
    SELF LOCK.NUT M16X1,5 WS=19
  • 27
    58404041100 CLOSING COVER ROUND
    CLOSING COVER ROUND
