SHIFTING MECHANISM (MOTOR NR/ENGINE NO B65002273 - B65 004044) для Ktm 65 SX - 2001 года выпуска

  • №
    Артикул
    Название
  • 1
    46034031000 SHIFTING LEVER CPL. 60/65 CCM
    SHIFTING LEVER CPL. 60/65 CCM
  • 2
    46034020000 SHIFT RAIL 10X83MM
    SHIFT RAIL 10X83MM
  • 3
    46034002000 SHIFT FORK COUNTERSHAFT
    SHIFT FORK COUNTERSHAFT
  • 4
    46034019000 SHIFT RAIL 10X72MM
    SHIFT RAIL 10X72MM
  • 5
    46034001000 SHIFT FORK MAIN SHAFT
    SHIFT FORK MAIN SHAFT
  • 6
    46034012200 SHIFT ROLLER
    SHIFT ROLLER
  • 8
    46034005044 SHIFT SHAFT CPL.
    SHIFT SHAFT CPL.
  • 10
    46034091000 SPACER WASHER 30X38 (SET)
    SPACER WASHER 30X38 (SET)
  • 11
    46034015100 SHIFT DRUM LOCATING
    SHIFT DRUM LOCATING
  • 12
    0991060303 FLAT HEAD SCREW DIN7991-M 6X30
    FLAT HEAD SCREW DIN7991-M 6X30
  • 14
    46034023000 LOCKING LEVER SPRING
    LOCKING LEVER SPRING
  • 15
    46034024000 LOCKING LEVER CPL.
    LOCKING LEVER CPL.
  • 16
    0799100000 TAB WASHER DIN6799-RS10,0
    TAB WASHER DIN6799-RS10,0
  • 20
    0760122050 SHAFT SEAL RING 12X20X5 B
    SHAFT SEAL RING 12X20X5 B
  • 24
    46034014000 RETURN SPRING
    RETURN SPRING
  • 25
    46034009000 PRESSURE SPRING SLIDER PLATE
    PRESSURE SPRING SLIDER PLATE
  • 26
    0912060203 AH SCREW DIN0912-M 6X20
    AH SCREW DIN0912-M 6X20
  • 27
    0797060003 TOOTH LOCK WASH. DIN6797-A 6,4
    TOOTH LOCK WASH. DIN6797-A 6,4
