SIDE COVER(S) W/ CHAIN COVER для Kawasaki KLR650 (KL650EDF) - 2013 года выпуска

  • №
    Артикул
    Название
  • 130
    130BA0640 BOLT-FLANGED, 6X40
    BOLT-FLANGED, 6X40
  • 186
    186BA0612 BOLT-UPSET-WP, 6X12
    BOLT-UPSET-WP, 6X12
  • 11045
    11045-1335 BRACKET, CHAIN CASE, FRONT
    BRACKET, CHAIN CASE, FRONT
  • 11054
    11054-0390 BRACKET, CHAIN CASE, REAR
    BRACKET, CHAIN CASE, REAR
  • 36034
    36034-5482-6C COVER-SIDE-SUB, LEFT HAND, (EBONY) (FOR 15G)
    COVER-SIDE-SUB, LEFT HAND, (EBONY) (FOR 15G)
  • 36034A
    36034-5483-6C COVER-SIDE-SUB, RIGHT HAND, (EBONY) (FOR 15G)
    COVER-SIDE-SUB, RIGHT HAND, (EBONY) (FOR 15G)
  • 36034B
    36034-5484-6C COVER-SIDE-SUB, LEFT HAND, (EBONY) (FOR 35P)
    COVER-SIDE-SUB, LEFT HAND, (EBONY) (FOR 35P)
  • 36034C
    36034-5485-6C COVER-SIDE-SUB, RIGHT HAND, (EBONY) (FOR 35P)
    COVER-SIDE-SUB, RIGHT HAND, (EBONY) (FOR 35P)
  • 36034D
    36034-5486-6C COVER-SIDE-SUB, LEFT HAND, (EBONY) (USA ONLY) (FOR H8)
    COVER-SIDE-SUB, LEFT HAND, (EBONY) (USA ONLY) (FOR H8)
  • 36034E
    36034-5487-6C COVER-SIDE-SUB, RIGHT HAND, (EBONY) (USA ONLY) (FOR H8)
    COVER-SIDE-SUB, RIGHT HAND, (EBONY) (USA ONLY) (FOR H8)
  • 39040
    39040-0003 COVER-ASSY-CHAIN CASE
    COVER-ASSY-CHAIN CASE
  • 39156
    39156-0652 PAD, SIDE COVER, RIGHT HAND, UPPER, FRONT
    PAD, SIDE COVER, RIGHT HAND, UPPER, FRONT
  • 39156A
    39156-0653 PAD, SIDE COVER, RIGHT HAND, UPPER, REAR
    PAD, SIDE COVER, RIGHT HAND, UPPER, REAR
  • 39156B
    39156-0654 PAD, SIDE COVER, RIGHT HAND, LOWER, REAR
    PAD, SIDE COVER, RIGHT HAND, LOWER, REAR
  • 39156C
    39156-0655 PAD, SIDE COVER, RIGHT HAND, LOWER, CNT
    PAD, SIDE COVER, RIGHT HAND, LOWER, CNT
  • 39156D
    39156-0656 PAD, SIDE COVER, RIGHT HAND, LOWER, FRONT
    PAD, SIDE COVER, RIGHT HAND, LOWER, FRONT
  • 92071
    92071-056 GROMMET
    GROMMET
  • 92152
    92152-0909 COLLAR, 8.8X11.2X4
    COLLAR, 8.8X11.2X4
  • 92154
    92154-0369 BOLT, FLANGED, 6X12
    BOLT, FLANGED, 6X12
