CLUTCH для Kawasaki KDX 200 - 2006 года выпуска

  • №
    Артикул
    Название
  • 130
    130Y0625 BOLT, FLANGED, 6X25
    BOLT, FLANGED, 6X25
  • 13086
    13086-1069 WHEEL, CLUTCH
    WHEEL, CLUTCH
  • 13087
    13087-1158 HUB, CLUTCH
    HUB, CLUTCH
  • 13088
    13088-1085 PLATE, FRICTION
    PLATE, FRICTION
  • 13089
    13089-1076 PLATE, CLUTCH
    PLATE, CLUTCH
  • 13091
    13091-1712 HOLDER, CLUTCH PUSHER
    HOLDER, CLUTCH PUSHER
  • 13091A
    13091-1872 HOLDER, CLUTCH SPRING
    HOLDER, CLUTCH SPRING
  • 13095
    13095-1287 HOUSING, COMP, CLUTCH
    HOUSING, COMP, CLUTCH
  • 13114
    13114-1067 PUSHER, CLUTCH
    PUSHER, CLUTCH
  • 13236
    13236-1264 LEVER, COMP, CLUTCH RELEASE
    LEVER, COMP, CLUTCH RELEASE
  • 16007
    16007-1162 SEAT, SPRING
    SEAT, SPRING
  • 92015
    92015-1581 NUT, 16MM
    NUT, 16MM
  • 92022
    92022-072 WASHER, 12.5X22X1.2
    WASHER, 12.5X22X1.2
  • 92022A
    92022-1181 WASHER, 10.2X14.5X1.0
    WASHER, 10.2X14.5X1.0
  • 92022B
    92022-1356 WASHER, 16.3X29X1.75
    WASHER, 16.3X29X1.75
  • 92028
    92028-1388 BUSHING, 20X25X26.85
    BUSHING, 20X25X26.85
  • 92045
    92045-1225 BEARING, BALL, 6000
    BEARING, BALL, 6000
  • 92144
    92144-1160 SPRING, CLUTCH
    SPRING, CLUTCH
  • 92144A
    92144-1287 SPRING, CLUTCH RELEASE
    SPRING, CLUTCH RELEASE
  • 92144B
    92144-1522 SPRING
    SPRING
  • 92200
    92200-1238 WASHER, 20.3X30X2.3
    WASHER, 20.3X30X2.3
