GEAR CHANGE DRUM W/ SHIFT FORK(S) для Kawasaki KX 65 - 2005 года выпуска`
-
№АртикулНазвание
-
610610A0408 ROLLER, 4X8ROLLER, 4X8
-
1314013140-1300 FORK, SHIFT, INPUTFORK, SHIFT, INPUT
-
13140A13140-1301 FORK, SHIFT, OUTPUTFORK, SHIFT, OUTPUT
-
1314113141-1220 DRUM, CHANGEDRUM, CHANGE
-
1327113271-1417 PLATEPLATE
-
1328013280-1179 HOLDERHOLDER
-
4904749047-1009 ROD, SHIFT, 10X90ROD, SHIFT, 10X90
-
9200992009-1862 SCREW, 6X14SCREW, 6X14
-
9204292042-014 PIN, DOWEL, 4X15.8PIN, DOWEL, 4X15.8
-
9215092150-1604 BOLT, SOCKET, 8X30BOLT, SOCKET, 8X30
