CARBURETOR для Kawasaki Lakota Sport (KEF300-B2) - 2002 года выпуска

  • №
    Артикул
    Название
  • 13091
    13091-1914 HOLDER, NEEDLE JET
    HOLDER, NEEDLE JET
  • 14030
    14030-1054 COVER, CARBURETOR
    COVER, CARBURETOR
  • 14041
    14041-1077 TOP, CHAMBER, MIXING, INSIDE
    TOP, CHAMBER, MIXING, INSIDE
  • 15003
    15003-1157 CARBURETOR, ASSY (EXCEPT CALIF)
    CARBURETOR, ASSY (EXCEPT CALIF)
  • 15003A
    15003-1363 CARBURETOR, ASSY (CALIF. ONLY)
    CARBURETOR, ASSY (CALIF. ONLY)
  • 16007
    16007-1120 SEAT, SPRING, THROTTLE VALVE
    SEAT, SPRING, THROTTLE VALVE
  • 16009
    16009-1516 NEEDLE, JET, N36X
    NEEDLE, JET, N36X
  • 16014
    16014-1081 SCREW, PILOT AIR
    SCREW, PILOT AIR
  • 16016
    16016-1101 PLUNGER, STARTER
    PLUNGER, STARTER
  • 16017
    16017-1335 JET, NEEDLE (EXCEPT CALIF)
    JET, NEEDLE (EXCEPT CALIF)
  • 16017A
    16017-1394 JET, NEEDLE, #6 (CALIF. ONLY)
    JET, NEEDLE, #6 (CALIF. ONLY)
  • 16021
    16021-1196 SCREW, THROTTLE STOP
    SCREW, THROTTLE STOP
  • 16030
    16030-1007 VALVE, FLOAT
    VALVE, FLOAT
  • 16031
    16031-1077 FLOAT
    FLOAT
  • 16044
    16044-007 CLAMP, FLOAT VALVE
    CLAMP, FLOAT VALVE
  • 16065
    16065-1301 HOLDER, CARBURETOR
    HOLDER, CARBURETOR
  • 16157
    16157-1057 JET, STARTER, #58
    JET, STARTER, #58
  • 43028
    43028-1080 DIAPHRAGM, VALVE
    DIAPHRAGM, VALVE
  • 49116
    49116-1126 VALVE, ASSY
    VALVE, ASSY
  • 92002
    92002-1143 BOLT, 6X16
    BOLT, 6X16
  • 92009
    92009-1551 SCREW, DRAIN, M6X0.75
    SCREW, DRAIN, M6X0.75
  • 92022
    92022-1380 WASHER, 5.2X13X1
    WASHER, 5.2X13X1
  • 92037
    92037-1201 CLAMP, TUBE
    CLAMP, TUBE
  • 92037A
    92037-1531 CLAMP, TUBE
    CLAMP, TUBE
  • 92055
    92055-1222 O-RING, FLOAT CHAMBER
    O-RING, FLOAT CHAMBER
  • 92055A
    92055-1295 O-RING, 38MM
    O-RING, 38MM
  • 92059
    92059-1538 TUBE, 6.5X11.5X200
    TUBE, 6.5X11.5X200
  • 92059A
    92059-1736 TUBE, 7X10X100
    TUBE, 7X10X100
  • 92059B
    92059-1861 TUBE, 6.5X9.5X320
    TUBE, 6.5X9.5X320
  • 92063
    92063-1013 JET, MAIN, #140 (EXCEPT CALIF)
    JET, MAIN, #140 (EXCEPT CALIF)
  • 92063A
    92063-1014 JET, MAIN, #135 (EXCEPT CALIF) (OPT)
    JET, MAIN, #135 (EXCEPT CALIF) (OPT)
  • 220
    220B0408 SCREW, PAN, CROS
    SCREW, PAN, CROS
  • 220A
    220D0414 SCREW, PAN, CROS
    SCREW, PAN, CROS
  • 92063B
    92063-1015 JET, MAIN, #138 (EXCEPT CALIF) (OPT)
    JET, MAIN, #138 (EXCEPT CALIF) (OPT)
  • 92063C
    92063-1016 JET, MAIN, #142 (OPT)
    JET, MAIN, #142 (OPT)
  • 92063D
    92063-1017 JET, MAIN, #145 (OPT)
    JET, MAIN, #145 (OPT)
  • 92063E
    92063-1324 JET, MAIN, #148 (CALIF. ONLY)
    JET, MAIN, #148 (CALIF. ONLY)
  • 92063F
    92063-1330 JET, MAIN, #150 (CALIF. ONLY) (OPT)
    JET, MAIN, #150 (CALIF. ONLY) (OPT)
  • 92063G
    92063-1331 JET, MAIN, #152 (CALIF. ONLY) (OPT)
    JET, MAIN, #152 (CALIF. ONLY) (OPT)
  • 92064
    92064-1119 JET, PILOT, #38
    JET, PILOT, #38
  • 92143
    92143-1589 COLLAR
    COLLAR
  • 92144
    92144-1745 SPRING, DIAPHRAGM VALVE
    SPRING, DIAPHRAGM VALVE
  • 92170
    92170-1438 CLAMP
    CLAMP
  • 92170A
    92170-1552 CLAMP
    CLAMP
  • 92190
    92190-1557 TUBE, 4.5X8X330
    TUBE, 4.5X8X330
