GEAR CHANGE DRUM/SHIFT FORK(S) для Kawasaki Prairie 300 4x4 (KVF300-A2) - 2000 года выпуска
-
№АртикулНазвание
-
1310713107-1414 SHAFT, IDLERSHAFT, IDLER
-
1313913139-1086 SHIFTER, FORWARD HI AND REVERSESHIFTER, FORWARD HI AND REVERSE
-
1326013260-1766 GEAR, FORWARD HIGH (43 TEETH)GEAR, FORWARD HIGH (43 TEETH)
-
13260A13260-1767 GEAR, FORWARD LOW (48 TEETH)GEAR, FORWARD LOW (48 TEETH)
-
13260B13260-1769 GEAR, IDLE SHAFT (36 TEETH)GEAR, IDLE SHAFT (36 TEETH)
-
3913539135-1059 SPROCKET-DRIVEN, REVERSE (37 TEETH)SPROCKET-DRIVEN, REVERSE (37 TEETH)
-
9202292022-1731 WASHER, 28.1X34X1.0WASHER, 28.1X34X1.0
-
9202692026-1066 SPACER, 20.3X30X1.8SPACER, 20.3X30X1.8
-
9203392033-026 RING-SNAP, 24MMRING-SNAP, 24MM
-
92033A92033-1037 RING-SNAP, 25.9X30.6X1.2RING-SNAP, 25.9X30.6X1.2
-
9220092200-1400 WASHER, 24.2X32X0.50WASHER, 24.2X32X0.50
-
92200A92200-1412 WASHER, 24.2X32X1.00WASHER, 24.2X32X1.00
