06- Brake для BRP Lynx 59 YETI - 2005
-
№АртикулНазвание
-
1512059624 Throttle handleThrottle handle
-
2512059489 Throttle handle housingThrottle handle housing
-
3414438700 PinPin
-
4414438900 WasherWasher
-
5414439000 CirclipCirclip
-
6414144408 Screw M8 x 10Screw M8 x 10
-
7515175410 Emergency switchEmergency switch
-
8572100901 CoverCover
-
9512059349 Throttle cableThrottle cable
-
1031038 CirclipCirclip
-
11293550004 Dielectric greaseDielectric grease
