FUEL PUMP ASSEMBLY для Arctic Cat ZR 3000 LXR 129 BLACK - 2017 года выпуска

  • №
    Артикул
    Название
  • 1
    0423-898 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 2
    2670-467 PROTECTOR, FUEL PUMP
    PROTECTOR, FUEL PUMP
  • 3
    2670-395 PLATE, RETAINING - FUEL PUMP
    PLATE, RETAINING - FUEL PUMP
  • 4
    2670-361 PUMP, FUEL - ASSEMBLY
    PUMP, FUEL - ASSEMBLY
  • 5
    0470-838 SEAL
    SEAL
  • 6
    1623-655 CLAMP, HOSE
    CLAMP, HOSE
  • 7
    2670-278 PICKUP, FUEL - ASSEMBLY
    PICKUP, FUEL - ASSEMBLY
  • 8
    1770-153 LINE, FUEL - TANK - ASSEMBLY
    LINE, FUEL - TANK - ASSEMBLY
  • 9
    2670-141 FITTING, QUICK-CONNECT
    FITTING, QUICK-CONNECT
  • 10
    0610-563 CLAMP, HOSE
    CLAMP, HOSE
  • 11
    0610-971 HOSE, FUEL - 10 FT
    HOSE, FUEL - 10 FT
  • 12
    2670-544 LINE, FUEL
    LINE, FUEL
  • 13
    0610-997 HOSE, FUEL - LINE
    HOSE, FUEL - LINE
  • 14
    1619-349 LOOM, 5/8" NON-SLIT - 5 FT
    LOOM, 5/8" NON-SLIT - 5 FT
  • 15
    1670-878 FITTING, QUICK-CONNECT
    FITTING, QUICK-CONNECT
  • 16
    0123-788 TIE, CABLE - 8 IN.
    TIE, CABLE - 8 IN.
  • 17
    0623-677 TIE, CABLE - PUSH MOUNT
    TIE, CABLE - PUSH MOUNT
