REAR SUSPENSION FRONT ARM ASSEMBLY для Arctic Cat BEARCAT 2000 LT BLUE - 2017 года выпуска

  • №
    Артикул
    Название
  • 1
    1704-671 ARM, FRONT SUSPENSION - BLACK (INC. 2-6)
    ARM, FRONT SUSPENSION - BLACK (INC. 2-6)
  • 2
    1623-010 ...FITTING, GREASE
    ...FITTING, GREASE
  • 3
    3604-141 ...BUMPER, FRONT SLIDER
    ...BUMPER, FRONT SLIDER
  • 4
    3604-968 ...PLATE, RETAINING
    ...PLATE, RETAINING
  • 5
    8060-708 ...RIVET
    ...RIVET
  • 6
    0104-386 ...BUSHING
    ...BUSHING
  • 7
    3604-272 AXLE, INNER
    AXLE, INNER
  • 8
    1423-064 SCREW, CAP
    SCREW, CAP
  • 9
    1623-992 WASHER, INTERNAL TOOTH LOCK
    WASHER, INTERNAL TOOTH LOCK
  • 10
    8422-002 NUT, LOCK
    NUT, LOCK
  • 11
    8427-602 NUT, LOCK
    NUT, LOCK
  • 12
    8450-109 WASHER
    WASHER
  • 13
    8408-620 SCREW, CAP
    SCREW, CAP
  • 14
    8408-630 SCREW, CAP
    SCREW, CAP
  • 15
    3604-274 STRAP, LIMITER
    STRAP, LIMITER
  • 16
    3604-234 AXLE, FRONT SLIDER
    AXLE, FRONT SLIDER
  • 17
    3604-233 BUSHING, FLARED
    BUSHING, FLARED
  • 18
    8408-041 SCREW, CAP
    SCREW, CAP
  • 19
    3604-334 SHOCK ABSORBER
    SHOCK ABSORBER
  • 20
    1604-791 BUSHING, SHOCK - 0.890 X 0.800
    BUSHING, SHOCK - 0.890 X 0.800
  • 21
    3604-273 AXLE
    AXLE
  • 22
    8408-050 SCREW, CAP
    SCREW, CAP
  • 23
    8427-002 NUT, LOCK
    NUT, LOCK
  • 24
    1603-889 RETAINER, SPRING
    RETAINER, SPRING
  • 25
    2603-719 RETAINER, SPRING
    RETAINER, SPRING
  • 26
    1704-236 SPRING, COMPRESSION - BLACK
    SPRING, COMPRESSION - BLACK
  • 27
    0604-790 COVER, SHOCK
    COVER, SHOCK
