A-ARM AND SWAY BAR ASSEMBLY для Arctic Cat ZR 6000 RXC (GREEN) (INTERNATIONAL) [S2015ACDCCOSG] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    3703-460 A-ARM, UPPER RIGHT - (WHITE)
    A-ARM, UPPER RIGHT - (WHITE)
  • 1
    3703-461 A-ARM, UPPER LEFT - (WHITE)
    A-ARM, UPPER LEFT - (WHITE)
  • 2
    8408-845 SCREW,CAP-HFH M8X1.25X45 CL8.8 Z & Y
    SCREW,CAP-HFH M8X1.25X45 CL8.8 Z & Y
  • 3
    2603-841 AXLE,A-ARM-UPPER-PM
    AXLE,A-ARM-UPPER-PM
  • 4
    8427-802 NUT,HEX FLG-NYL LOCK M8X1.25 CL8 Z & Y
    NUT,HEX FLG-NYL LOCK M8X1.25 CL8 Z & Y
  • 5
    8427-202 NUT,HEX FLG-NYL LOCK M12X1.25 CL8 Z & Y
    NUT,HEX FLG-NYL LOCK M12X1.25 CL8 Z & Y
  • 6
    2603-944 BUSHING,SWAYBAR-11.1MM-INNER
    BUSHING,SWAYBAR-11.1MM-INNER
  • 7
    2703-615 SWAYBAR,FORMED-11.1MM-PTD (BLACK)
    SWAYBAR,FORMED-11.1MM-PTD (BLACK)
  • 8
    2603-945 BUSHING,SWAYBAR-11.1MM-OUTER
    BUSHING,SWAYBAR-11.1MM-OUTER
  • 9
    2603-857 BRACKET, MOUNTING - SWAY BAR
    BRACKET, MOUNTING - SWAY BAR
  • 10
    8468-621 SCREW,MACH-TSPNH M6X1.0X20 CL8.8 W/2353
    SCREW,MACH-TSPNH M6X1.0X20 CL8.8 W/2353
  • 11
    8476-835 SCREW,MACH-TSTRH M8X1.25X35 Z & Y
    SCREW,MACH-TSTRH M8X1.25X35 Z & Y
  • 12
    3603-295 LINK, SWAY BAR
    LINK, SWAY BAR
  • 13
    3703-462 A-ARM, LOWER RIGHT - (WHITE) (INC. 14-15)
    A-ARM, LOWER RIGHT - (WHITE) (INC. 14-15)
  • 13
    3703-463 A-ARM, LOWER LEFT - (WHITE) (INC. 14-15)
    A-ARM, LOWER LEFT - (WHITE) (INC. 14-15)
  • 14
    1603-895 ...BEARING, 10DU10-FRONT SUSPENSION
    ...BEARING, 10DU10-FRONT SUSPENSION
  • 15
    2603-911 ...BEARING,SPLIT-18 X 20 X 15
    ...BEARING,SPLIT-18 X 20 X 15
  • 16
    1623-965 NUT,HEX-THK NYL M12X1.25 CL8 Z & Y(DIN)
    NUT,HEX-THK NYL M12X1.25 CL8 Z & Y(DIN)
  • 17
    2603-909 BRACE, LOWER A-ARM - FRONT
    BRACE, LOWER A-ARM - FRONT
  • 18
    2603-916 AXLE, INNER - LOWER A-ARM - FRONT
    AXLE, INNER - LOWER A-ARM - FRONT
  • 19
    1623-953 SCREW,CAP-HFH M12X1.25X76 CL 10.9 MZ
    SCREW,CAP-HFH M12X1.25X76 CL 10.9 MZ
  • 20
    8409-075 SCREW,CAP-HFH M10X1.25X75 CL10.9 Z & Y
    SCREW,CAP-HFH M10X1.25X75 CL10.9 Z & Y
  • 21
    2603-543 AXLE, LOWER A-ARM - REAR
    AXLE, LOWER A-ARM - REAR
  • 22
    8427-002 NUT,HEX FLG-NYL LOCK M10X1.25 CL8 Z & Y
    NUT,HEX FLG-NYL LOCK M10X1.25 CL8 Z & Y
