WINDSHIELD AND INSTRUMENTS ASSEMBLIES для Arctic Cat XF 7000 CROSS-TOUR 141 (ORANGE) [S2015X7UCTUSO] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    5706-694 POD, INSTRUMENT ORANGE
    POD, INSTRUMENT ORANGE
  • 2
    1623-129 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 3
    0641-897 OUTLET, ACCESSORY - 12V
    OUTLET, ACCESSORY - 12V
  • 4
    6606-556 VENT
    VENT
  • 5
    0609-911 SWITCH, IGNITION (INC. 6-8)
    SWITCH, IGNITION (INC. 6-8)
  • 6
    0430-050 ...NUT, FLANGE - IGNITION SWITCH
    ...NUT, FLANGE - IGNITION SWITCH
  • 7
    0430-042 ...KEY, IGNITION - (Y SERIES - LEFT-SIDE CUT)
    ...KEY, IGNITION - (Y SERIES - LEFT-SIDE CUT)
  • 7
    0430-043 ...KEY, IGNITION - (Z SERIES - RIGHT-SIDE CUT)
    ...KEY, IGNITION - (Z SERIES - RIGHT-SIDE CUT)
  • 8
    0430-054 ...COVER, KEY
    ...COVER, KEY
  • 9
    0720-019 GAUGE, SPEEDOMETER
    GAUGE, SPEEDOMETER
  • 10
    2623-042 SCREW, SHOULDER
    SCREW, SHOULDER
  • 11
    1623-025 GROMMET, SCREW-PLASTIC
    GROMMET, SCREW-PLASTIC
  • 12
    6606-722 WINDSHIELD, MID CRUISER W/ HOLES
    WINDSHIELD, MID CRUISER W/ HOLES
  • 13
    2623-146 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 14
    6639-629 MIRROR KIT - SINGLE (INC. SIX NO. 15-17)
    MIRROR KIT - SINGLE (INC. SIX NO. 15-17)
  • 14
    6639-630 MIRROR KIT - PAIR (INC. SIX NO. 15-17)
    MIRROR KIT - PAIR (INC. SIX NO. 15-17)
  • 15
    1623-764 ...NUT, EXPANSION
    ...NUT, EXPANSION
  • 16
    8477-516 ...SCREW, MACHINE
    ...SCREW, MACHINE
  • 17
    0124-054 ...CAP, SNAP W/ WASHER
    ...CAP, SNAP W/ WASHER
