WATER HOSE ASSEMBLY для Arctic Cat BEARCAT 5000 XT LTD (BLACK) [S2015BCNWLUSB] - 2015 года выпуска
-
№АртикулНазвание
-
13007-182 THERMOSTATTHERMOSTAT
-
23003-924 CAP, THERMOSTAT (U.S.)CAP, THERMOSTAT (U.S.)
-
33007-369 BOLT,CYLINDER HEAD COVER NO. 1BOLT,CYLINDER HEAD COVER NO. 1
-
43007-513 HOSE, INLETHOSE, INLET
-
53007-184 HOSE, BYPASS - NO. 1HOSE, BYPASS - NO. 1
-
63007-514 HOSE, BYPASS - NO. 2HOSE, BYPASS - NO. 2
-
73007-186 HOSE, BYPASS - NO. 3HOSE, BYPASS - NO. 3
-
83007-187 FITTING, HOSEFITTING, HOSE
-
93007-188 CLAMP, HOSE - NO. 1CLAMP, HOSE - NO. 1
-
103007-189 CLIP,WATER BYPASS HOSE NO.3CLIP,WATER BYPASS HOSE NO.3
-
113008-488 CLIP (ID:17.8)CLIP (ID:17.8)
-
123007-857 CLAMP, HOSECLAMP, HOSE
-
133007-190 FITTING, HOSEFITTING, HOSE
-
140830-173 O-RINGO-RING
-
153007-515 BOLT,WATER INLET CONNECTORBOLT,WATER INLET CONNECTOR
-
163007-516 CLIP, RETAININGCLIP, RETAINING
Все узлы модели:
- A-ARM AND SWAY BAR ASSEMBLY
- AIR SILENCER ASSEMBLY
- ARTICULATING SKID FRAME ASSEMBLY
- BATTERY AND TRAY ASSEMBLY
- BELT GUARD ASSEMBLY
- CAM CHAIN ASSEMBLY
- CAMSHAFT/VALVE ASSEMBLY
- CENTER PASSENGER SEAT ASSEMBLY
- CHASSIS ASSEMBLY
- CONSOLE ASSEMBLY
- COOLING ASSEMBLY
- CRANK BALANCER ASSEMBLY
- CRANKCASE ASSEMBLY
- CYLINDER HEAD ASSEMBLY
- DRIVE CLUTCH
- DRIVE TRAIN SHAFT AND BRAKE ASSEMBLIES
- DRIVEN CLUTCH
- ENGINE AND RELATED PARTS
- EXHAUST ASSEMBLY
- EXHAUST MANIFOLD GASKET/INTAKE FLANGE ASSEMBLY
- FRONT SEAT ASSEMBLY
- FRONT SHOCK ABSORBER ASSEMBLY
- FUEL PUMP ASSEMBLY
- GAS TANK ASSEMBLY
- GEARCASE ASSEMBLY
- HANDLEBAR AND CONTROLS
- HEADLIGHT AND WIRING ASSEMBLIES
- HOOD- WINDSHIELD- AND FRONT BUMPER ASSEMBLY
- HYDRAULIC BRAKE CONTROL ASSEMBLY
- IDLER WHEEL ASSEMBLY
- MAGNETO ASSEMBLY
- MAGNETO COVER
- OIL COOLER ASSEMBLY
- OIL PAN ASSEMBLY
- OIL PUMP ASSEMBLY
- OIL SEPARATOR ASSEMBLY
- OIL TANK ASSEMBLY
- PISTON AND CRANKSHAFT ASSEMBLY
- REAR BUMPER- RACK RAIL- SNOWFLAP- AND TAILLIGHT ASSEMBLY
- REAR PASSENGER SEAT AND BACKREST ASSEMBLY
- SEAT SUPPORT ASSEMBLY
- SKI AND SPINDLE ASSEMBLY
- SKID PLATE AND SIDE PANEL ASSEMBLY
- STARTER CLUTCH ASSEMBLY
- STARTER MOTOR ASSEMBLY
- STEERING POST ASSEMBLY
- STEERING SUPPORT ASSEMBLY
- SUSPENSION FRONT - FRONT ARM ASSEMBLY
- SUSPENSION REAR - REAR ARM ASSEMBLY
- THROTTLE BODY ASSEMBLY
- TIE ROD ASSEMBLY
- TRACK ASSEMBLY W/ SLIDE RAIL
- • WATER HOSE ASSEMBLY
- WATER PUMP ASSEMBLY
