HOOD- WINDSHIELD- AND FRONT BUMPER ASSEMBLY для Arctic Cat AC F5 EFI LXR - 2009 года выпуска

  • №
    Артикул
    Название
  • 1
    2718-573 HOOD W/DECALS - GREEN (INC. 2-9)
    HOOD W/DECALS - GREEN (INC. 2-9)
  • 2
    7999-263 ...HOOD W/O DECALS - GREEN (INC. 3-7)
    ...HOOD W/O DECALS - GREEN (INC. 3-7)
  • 3
    4606-624 ......VENT, HOOD - OUTER FRONT - RIGHT - BLACK
    ......VENT, HOOD - OUTER FRONT - RIGHT - BLACK
  • 3
    4606-625 ......VENT, HOOD - OUTER FRONT - LEFT - BLACK
    ......VENT, HOOD - OUTER FRONT - LEFT - BLACK
  • 4
    4606-640 ......VENT, HOOD - OUTER REAR - RIGHT - BLACK
    ......VENT, HOOD - OUTER REAR - RIGHT - BLACK
  • 4
    4606-641 ......VENT, HOOD - OUTER REAR - LEFT - BLACK
    ......VENT, HOOD - OUTER REAR - LEFT - BLACK
  • 5
    4606-614 ......VENT, HOOD - INNER - RIGHT - BLACK
    ......VENT, HOOD - INNER - RIGHT - BLACK
  • 5
    4606-615 ......VENT, HOOD - INNER - LEFT - BLACK
    ......VENT, HOOD - INNER - LEFT - BLACK
  • 6
    1623-614 ......CLIP, RUBBER - HOOD HOLD-DOWN - RIGHT
    ......CLIP, RUBBER - HOOD HOLD-DOWN - RIGHT
  • 6
    1623-615 ......CLIP, RUBBER - HOOD HOLD-DOWN - LEFT
    ......CLIP, RUBBER - HOOD HOLD-DOWN - LEFT
  • 7
    1623-610 ......PIN, RETAINING
    ......PIN, RETAINING
  • 8
    8611-418 ...DECAL, HOOD - RIGHT
    ...DECAL, HOOD - RIGHT
  • 8
    8611-419 ...DECAL, HOOD - LEFT
    ...DECAL, HOOD - LEFT
  • 9
    8611-403 ...DECAL, HOOD - CREST
    ...DECAL, HOOD - CREST
  • 10
    3706-348 BRACKET, HINGE - RIGHT
    BRACKET, HINGE - RIGHT
  • 10
    3706-347 BRACKET, HINGE - LEFT
    BRACKET, HINGE - LEFT
  • 11
    1623-469 NUT, STAMPED
    NUT, STAMPED
  • 12
    1623-129 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 13
    2718-552 SPAR, FRONT W/DECALS - RIGHT (INC. 14-16)
    SPAR, FRONT W/DECALS - RIGHT (INC. 14-16)
  • 13
    2718-553 SPAR, FRONT W/DECALS - LEFT (INC. 14 AND 16)
    SPAR, FRONT W/DECALS - LEFT (INC. 14 AND 16)
  • 14
    4606-884 ...SPAR, FRONT W/O DECALS - RIGHT - BLACK
    ...SPAR, FRONT W/O DECALS - RIGHT - BLACK
  • 14
    4606-885 ...SPAR, FRONT W/O DECALS - LEFT - BLACK
    ...SPAR, FRONT W/O DECALS - LEFT - BLACK
  • 15
    4606-934 ...FOIL, SPAR - RIGHT
    ...FOIL, SPAR - RIGHT
  • 16
    8611-414 ...DECAL, FRONT SPAR - RIGHT
    ...DECAL, FRONT SPAR - RIGHT
  • 16
    8611-415 ...DECAL, FRONT SPAR - LEFT
    ...DECAL, FRONT SPAR - LEFT
  • 17
    5606-920 BEZEL, INTAKE - RIGHT - GREEN
    BEZEL, INTAKE - RIGHT - GREEN
  • 17
    5606-921 BEZEL, INTAKE - LEFT - GREEN
    BEZEL, INTAKE - LEFT - GREEN
  • 18
    1623-677 RIVET, PLASTIC
    RIVET, PLASTIC
  • 19
    4606-961 BRACKET, WINDSHIELD - HOLD-DOWN
    BRACKET, WINDSHIELD - HOLD-DOWN
  • 20
    5606-961 WINDSHIELD
    WINDSHIELD
  • 21
    2718-548 FASCIA, BUMPER W/DECALS - GREEN (INC. 22-23)
    FASCIA, BUMPER W/DECALS - GREEN (INC. 22-23)
  • 22
    4606-519 ...FASCIA, BUMPER - UPPER - GREEN
    ...FASCIA, BUMPER - UPPER - GREEN
  • 23
    8611-267 ...DECAL, AIRCAT - CHROME
    ...DECAL, AIRCAT - CHROME
  • 24
    4606-512 BUMPER, FRONT - BLACK
    BUMPER, FRONT - BLACK
  • 25
    4606-604 VENT, BUMPER - RIGHT - BLACK
    VENT, BUMPER - RIGHT - BLACK
  • 25
    4606-605 VENT, BUMPER - LEFT - BLACK
    VENT, BUMPER - LEFT - BLACK
  • 26
    2718-544 FASCIA, BUMPER - LOWER W/DECALS (INC. 27-28)
    FASCIA, BUMPER - LOWER W/DECALS (INC. 27-28)
  • 27
    5606-462 ...FASCIA, BUMPER - LOWER W/O DECALS - BLACK
    ...FASCIA, BUMPER - LOWER W/O DECALS - BLACK
  • 28
    8611-416 ...DECAL, FASCIA - LOWER - RIGHT
    ...DECAL, FASCIA - LOWER - RIGHT
  • 28
    8611-417 ...DECAL, FASCIA - LOWER - LEFT
    ...DECAL, FASCIA - LOWER - LEFT
  • 29
    0423-355 SCREW, SHOULDER
    SCREW, SHOULDER
  • 30
    8427-602 NUT, LOCK
    NUT, LOCK
  • 31
    1623-775 SCREW, SHOULDER
    SCREW, SHOULDER
  • 32
    8424-602 NUT
    NUT
  • 33
    0623-966 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 34
    8053-242 WASHER, EXTERNAL TOOTH LOCK
    WASHER, EXTERNAL TOOTH LOCK
  • 35
    4606-926 STRAP, HOLD-DOWN
    STRAP, HOLD-DOWN
