SLIDE RAIL AND TRACK ASSEMBLY для Arctic Cat PANTHER 370 TOURING - 2008 года выпуска`
-
№АртикулНазвание
-
7999-144 COMPLETE SKID FRAME ASSEMBLYCOMPLETE SKID FRAME ASSEMBLY
-
12604-712 RAIL, FORMEDRAIL, FORMED
-
20604-426 SUPPORT, RAILSUPPORT, RAIL
-
38047-366 NUT, LOCKNUT, LOCK
-
48050-217 WASHERWASHER
-
52604-842 END CAP, SLIDE RAILEND CAP, SLIDE RAIL
-
68002-043 SCREW, CAPSCREW, CAP
-
70123-859 SCREW, MACHINESCREW, MACHINE
-
82604-257 WEARSTRIP, SLIDE RAIL - BLACKWEARSTRIP, SLIDE RAIL - BLACK
-
91623-502 SCREW, CAPSCREW, CAP
-
108060-633 RIVET, SOLIDRIVET, SOLID
-
110604-967 BRACKET, RETAININGBRACKET, RETAINING
-
120604-918 PAD, SHOCKPAD, SHOCK
-
138047-426 NUT, LOCKNUT, LOCK
-
140704-395 BRACKET, MOUNTING - FRONT ARMBRACKET, MOUNTING - FRONT ARM
-
158020-132 SCREW, CAPSCREW, CAP
-
168020-227 SCREW, CAPSCREW, CAP
-
171604-413 BLOCK, SPRING TENSIONBLOCK, SPRING TENSION
-
188047-486 NUT, LOCKNUT, LOCK
-
198041-246 NUT, LOCKNUT, LOCK
-
201604-429 PAD, SHOCKPAD, SHOCK
-
218017-405 SCREW, MACHINESCREW, MACHINE
-
222604-562 STOP, REAR ARMSTOP, REAR ARM
-
231623-427 SCREW, CAPSCREW, CAP
-
248002-042 SCREW, CAPSCREW, CAP
-
250704-352 ADJUSTER, TRACKADJUSTER, TRACK
-
261602-476 TRACK ASSEMBLY (INC. 27)TRACK ASSEMBLY (INC. 27)
-
271602-907 ...CLIP, GUIDE...CLIP, GUIDE
