CHASSIS- FOOTREST- AND REAR BUMPER ASSEMBLY для Arctic Cat AC 120 (GREEN) - 2008 года выпуска

  • №
    Артикул
    Название
  • 1
    2718-539 TUNNEL ASSEMBLY (INC. 2-4)
    TUNNEL ASSEMBLY (INC. 2-4)
  • 2
    2706-156 ...PLATE, REINFORCEMENT - TUNNEL - RIGHT
    ...PLATE, REINFORCEMENT - TUNNEL - RIGHT
  • 2
    2706-157 ...PLATE, REINFORCEMENT - TUNNEL - LEFT
    ...PLATE, REINFORCEMENT - TUNNEL - LEFT
  • 3
    1606-740 ...PLATE, COVER - TUNNEL
    ...PLATE, COVER - TUNNEL
  • 4
    0123-418 ...RIVET, SOLID
    ...RIVET, SOLID
  • 5
    2706-141 BRACKET, MOUNTING - HOOD - LOWER
    BRACKET, MOUNTING - HOOD - LOWER
  • 6
    3706-774 PLATE, REINFORCEMENT
    PLATE, REINFORCEMENT
  • 7
    0623-892 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 8
    8060-504 RIVET, BLIND
    RIVET, BLIND
  • 9
    8060-506 RIVET, BLIND
    RIVET, BLIND
  • 10
    2706-180 BRACKET, SUPPORT - FOOTREST - RIGHT
    BRACKET, SUPPORT - FOOTREST - RIGHT
  • 10
    2706-181 BRACKET, SUPPORT - FOOTREST - LEFT
    BRACKET, SUPPORT - FOOTREST - LEFT
  • 11
    1606-784 FOOTREST - RIGHT
    FOOTREST - RIGHT
  • 11
    1606-785 FOOTREST - LEFT
    FOOTREST - LEFT
  • 12
    8020-040 SCREW, CAP
    SCREW, CAP
  • 13
    8041-366 NUT, LOCK
    NUT, LOCK
  • 14
    3706-772 SUPPORT, FOOTREST - RIGHT
    SUPPORT, FOOTREST - RIGHT
  • 14
    3706-773 SUPPORT, FOOTREST - LEFT
    SUPPORT, FOOTREST - LEFT
  • 15
    1606-750 SNOWFLAP
    SNOWFLAP
  • 16
    0123-802 WASHER
    WASHER
  • 17
    8060-628 RIVET, BLIND
    RIVET, BLIND
  • 18
    3706-777 BUMPER, REAR - PLATINUM
    BUMPER, REAR - PLATINUM
  • 19
    3606-994 END CAP, REAR BUMPER - RIGHT
    END CAP, REAR BUMPER - RIGHT
  • 19
    3606-995 END CAP, REAR BUMPER - LEFT
    END CAP, REAR BUMPER - LEFT
  • 20
    8060-706 RIVET, BLIND
    RIVET, BLIND
  • 21
    0623-562 PLUG, HOLE
    PLUG, HOLE
  • 22
    6611-688 DECAL, REFLECTOR - RIGHT
    DECAL, REFLECTOR - RIGHT
  • 22
    6611-689 DECAL, REFLECTOR - LEFT
    DECAL, REFLECTOR - LEFT
  • 23
    1706-105 FLAG, SAFETY - ASSEMBLY (INC. 24-27)
    FLAG, SAFETY - ASSEMBLY (INC. 24-27)
  • 24
    1706-104 ...FLAG, SAFETY
    ...FLAG, SAFETY
  • 25
    1606-954 ...POLE, SAFETY FLAG
    ...POLE, SAFETY FLAG
  • 26
    2606-010 ...MOUNTING, SAFETY FLAG - ASSEMBLY
    ...MOUNTING, SAFETY FLAG - ASSEMBLY
  • 27
    8020-134 ...SCREW, CAP
    ...SCREW, CAP
  • 28
    7611-943 DECAL, REAR BUMPER (GREEN)
    DECAL, REAR BUMPER (GREEN)
  • 28
    8611-148 DECAL, REAR BUMPER (PINK)
    DECAL, REAR BUMPER (PINK)
  • 29
    0623-301 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 30
    2706-217 COVER, SPROCKET - DRIVEN
    COVER, SPROCKET - DRIVEN
  • 31
    3611-754 DECAL, WARNING - COVER
    DECAL, WARNING - COVER
  • 32
    8020-045 SCREW, CAP
    SCREW, CAP
  • 33
    0630-001 REGULATOR, VOLTAGE
    REGULATOR, VOLTAGE
  • 34
    8047-366 NUT, LOCK
    NUT, LOCK
  • 35
    0623-677 CABLE TIE, PUSH-MOUNT
    CABLE TIE, PUSH-MOUNT
  • 36
    0123-788 CABLE TIE
    CABLE TIE
  • 37
    7611-946 DECAL, TUNNEL - RIGHT (GREEN)
    DECAL, TUNNEL - RIGHT (GREEN)
  • 37
    7611-947 DECAL, TUNNEL - LEFT (GREEN)
    DECAL, TUNNEL - LEFT (GREEN)
  • 37
    8611-126 DECAL, TUNNEL - RIGHT (PINK)
    DECAL, TUNNEL - RIGHT (PINK)
  • 37
    8611-127 DECAL, TUNNEL - LEFT (PINK)
    DECAL, TUNNEL - LEFT (PINK)
