GAS TANK- SEAT- AND TAILLIGHT ASSY. для Arctic Cat ZR 120 - 2004 года выпуска`
-
№АртикулНазвание
-
-1718-331 COMPLETE SEAT ASSY.COMPLETE SEAT ASSY.
-
11718-331 COMPLETE SEAT ASSY. (INC. 2, 8 AND 20)COMPLETE SEAT ASSY. (INC. 2, 8 AND 20)
-
22606-844 TANK, GAS/SEAT, BASETANK, GAS/SEAT, BASE
-
31706-143 COVER, SEATCOVER, SEAT
-
41706-017 FOAM, SEATFOAM, SEAT
-
51670-084 CAP, GAS TANK (INC. 6)CAP, GAS TANK (INC. 6)
-
60109-733 SEAL, TANK CAPSEAL, TANK CAP
-
72606-942 WIRE, SEATWIRE, SEAT
-
82606-031 WIRE, SEATWIRE, SEAT
-
90676-017 VALVE, SHUT, OFF, GAS TANKVALVE, SHUT, OFF, GAS TANK
-
106101-001 HOSE, GASLINE/VENT (100 FT)HOSE, GASLINE/VENT (100 FT)
-
106101-009 HOSE, GASLINE/VENT (50 FT)HOSE, GASLINE/VENT (50 FT)
-
110510-335 FILTER, FUELFILTER, FUEL
-
120670-289 TAPE, TEFLONTAPE, TEFLON
-
130609-070 TAILLIGHT ASSY. (INC. 14)TAILLIGHT ASSY. (INC. 14)
-
140230-020 BULB, TAILLIGHTBULB, TAILLIGHT
-
158050-157 WASHERWASHER
-
160123-709 NUT W/LOCK WASHERNUT W/LOCK WASHER
-
170623-184 WASHERWASHER
-
180123-108 NUT, NYLON CAPNUT, NYLON CAP
-
190687-154 CABLE, CHOKE (INC. 21)CABLE, CHOKE (INC. 21)
-
200624-528 STAPLE, SEAT COVERSTAPLE, SEAT COVER
-
210687-181 NUT, CHOKE CABLENUT, CHOKE CABLE
-
224611-767 DECAL, SWITCH/CHOKEDECAL, SWITCH/CHOKE
-
230609-111 NUT, RETAININGNUT, RETAINING
-
240109-822 SWITCH, IGNITION (INC. 23 AND 25)SWITCH, IGNITION (INC. 23 AND 25)
-
250116-065 KEYKEY
-
268041-366 NUT, LOCKNUT, LOCK
-
278002-040 SCREW, CAPSCREW, CAP
-
283611-856 DECAL, SHUT, OFF VALVEDECAL, SHUT, OFF VALVE
-
290123-579 NUT, PUSHNUT, PUSH
-
300123-788 CABLE TIE, 7 IN.CABLE TIE, 7 IN.
-
310123-394 CLIP, CABLECLIP, CABLE
-
320116-469 BUSHING, RECOIL STARTERBUSHING, RECOIL STARTER
