CAMSHAFT/VALVE ASSEMBLY для Arctic Cat Bearcat Wide Track (International) - 2004 года выпуска

№

Артикул

Название
1

3006-574 CAMSHAFT, INTAKE

CAMSHAFT, INTAKE
2

3006-575 CAMSHAFT, EXHAUST

CAMSHAFT, EXHAUST
3

3006-198 VALVE, INTAKE

VALVE, INTAKE
4

3006-199 VALVE, EXHAUST

VALVE, EXHAUST
5

3006-576 SPRING, VALVE

SPRING, VALVE
6

3006-201 RETAINER

RETAINER
7

3006-202 COTTER, VALVE

COTTER, VALVE
8

3006-203 SEAT, SPRING

SEAT, SPRING
9

3006-125 SEAL, VALVE STEM

SEAL, VALVE STEM
10

3006-171 TAPPET

TAPPET
11

3006-172 SHIM, TAPPET, 2.30 MM

SHIM, TAPPET, 2.30 MM
11

3006-173 SHIM, TAPPET, 2.32 MM

SHIM, TAPPET, 2.32 MM
11

3006-174 SHIM, TAPPET, 2.34 MM

SHIM, TAPPET, 2.34 MM
11

3006-175 SHIM, TAPPET, 2.36 MM

SHIM, TAPPET, 2.36 MM
11

3006-176 SHIM, TAPPET, 2.38 MM

SHIM, TAPPET, 2.38 MM
11

3006-177 SHIM, TAPPET, 2.40 MM

SHIM, TAPPET, 2.40 MM
11

3006-178 SHIM, TAPPET, 2.42 MM

SHIM, TAPPET, 2.42 MM
11

3006-179 SHIM, TAPPET, 2.44 MM

SHIM, TAPPET, 2.44 MM
11

3006-180 SHIM, TAPPET, 2.46 MM

SHIM, TAPPET, 2.46 MM
11

3006-181 SHIM, TAPPET, 2.48 MM

SHIM, TAPPET, 2.48 MM
11

3006-182 SHIM, TAPPET, 2.50 MM

SHIM, TAPPET, 2.50 MM
11

3006-183 SHIM, TAPPET, 2.52 MM

SHIM, TAPPET, 2.52 MM
11

3006-184 SHIM, TAPPET, 2.54 MM

SHIM, TAPPET, 2.54 MM
11

3006-185 SHIM, TAPPET, 2.56 MM

SHIM, TAPPET, 2.56 MM
11

3006-186 SHIM, TAPPET, 2.58 MM

SHIM, TAPPET, 2.58 MM
11

3006-187 SHIM, TAPPET, 2.60 MM

SHIM, TAPPET, 2.60 MM
11

3006-188 SHIM, TAPPET, 2.62 MM

SHIM, TAPPET, 2.62 MM
11

3006-189 SHIM, TAPPET, 2.64 MM

SHIM, TAPPET, 2.64 MM
11

3006-190 SHIM, TAPPET, 2.66 MM

SHIM, TAPPET, 2.66 MM
11

3006-191 SHIM, TAPPET, 2.68 MM

SHIM, TAPPET, 2.68 MM
11

3006-192 SHIM, TAPPET, 2.70 MM

SHIM, TAPPET, 2.70 MM
11

3006-193 SHIM, TAPPET, 2.72 MM

SHIM, TAPPET, 2.72 MM
11

3006-194 SHIM, TAPPET, 2.74 MM

SHIM, TAPPET, 2.74 MM
11

3006-195 SHIM, TAPPET, 2.76 MM

SHIM, TAPPET, 2.76 MM
11

3006-196 SHIM, TAPPET, 2.78 MM

SHIM, TAPPET, 2.78 MM
11

3006-197 SHIM, TAPPET, 2.80 MM

SHIM, TAPPET, 2.80 MM
