WHEEL AND TIRE ASSEMBLY для Arctic Cat HDX 700 CREW XT RED - 2017 года выпуска

  • №
    Артикул
    Название
  • 1
    0423-557 SCREW, SHOULDER
    SCREW, SHOULDER
  • 2
    1436-807 KIT, BRAKE DISC (INC. 1)
    KIT, BRAKE DISC (INC. 1)
  • 3
    2502-384 HUB ASSEMBLY (FRONT) (INC. 4)
    HUB ASSEMBLY (FRONT) (INC. 4)
  • 3
    2502-386 HUB ASSEMBLY (REAR) (INC. 4)
    HUB ASSEMBLY (REAR) (INC. 4)
  • 4
    2402-351 ...STUD, WHEEL
    ...STUD, WHEEL
  • 5
    2402-356 PLATE, HUB
    PLATE, HUB
  • 6
    0423-607 NUT, CASTLE
    NUT, CASTLE
  • 7
    2402-263 WHEEL - FRONT (INC. 8) - RED
    WHEEL - FRONT (INC. 8) - RED
  • 8
    2402-277 ...CAP, WHEEL - RED
    ...CAP, WHEEL - RED
  • 9
    0402-064 STEM, VALVE - W/CAP
    STEM, VALVE - W/CAP
  • 10
    1423-337 NUT, WHEEL - M12-BLK
    NUT, WHEEL - M12-BLK
  • 11
    1402-953 TIRE - FRONT - DURO KADEN - 26X9-14
    TIRE - FRONT - DURO KADEN - 26X9-14
  • 12
    2402-264 WHEEL - REAR (INC. 8) - RED
    WHEEL - REAR (INC. 8) - RED
  • 13
    1402-954 TIRE - REAR - DURO KADEN - 26X11-14
    TIRE - REAR - DURO KADEN - 26X11-14
