STEERING ASSEMBLY для Arctic Cat ALTERRA 700 RED [A2016XAT4EUSR] - 2016 года выпуска

  • №
    Артикул
    Название
  • 1
    8408-835 SCREW, CAP
    SCREW, CAP
  • 2
    0405-035 CAP, STEERING ADJUSTER
    CAP, STEERING ADJUSTER
  • 3
    0505-898 CAP, HOUSING - BLACK
    CAP, HOUSING - BLACK
  • 4
    4406-787 BRACKET, SUPPORT - CONSOLE
    BRACKET, SUPPORT - CONSOLE
  • 5
    0405-259 BLOCK, MOUNTING
    BLOCK, MOUNTING
  • 6
    0505-884 POST, STEERING - BLACK
    POST, STEERING - BLACK
  • 7
    0423-505 SCREW, SHOULDER
    SCREW, SHOULDER
  • 8
    8476-616 SCREW, MACHINE
    SCREW, MACHINE
  • 9
    0405-550 FLANGE, BEARING
    FLANGE, BEARING
  • 10
    0405-549 BEARING W/INVERTED OIL SEAL
    BEARING W/INVERTED OIL SEAL
  • 11
    8450-109 WASHER
    WASHER
  • 12
    8408-613 SCREW, CAP
    SCREW, CAP
  • 13
    0505-885 ROD, TIE - ASSEMBLY (INC. 14-20)
    ROD, TIE - ASSEMBLY (INC. 14-20)
  • 14
    0505-875 ...END, TIE ROD - LEFT-HAND THREAD - KIT
    ...END, TIE ROD - LEFT-HAND THREAD - KIT
  • 15
    0423-013 NUT - LEFT-HAND THREAD
    NUT - LEFT-HAND THREAD
  • 16
    0623-175 PIN, COTTER
    PIN, COTTER
  • 17
    0423-157 NUT
    NUT
  • 18
    0405-521 ROD, TIE
    ROD, TIE
  • 19
    0405-502 END, TIE ROD - RIGHT-HAND THREAD - KIT (INC. ONE NO. 16-17 AND 20)
    END, TIE ROD - RIGHT-HAND THREAD - KIT (INC. ONE NO. 16-17 AND 20)
  • 20
    8420-002 ...NUT - RIGHT-HAND THREAD
    ...NUT - RIGHT-HAND THREAD
