AIR INTAKE ASSEMBLY для Arctic Cat ALTERRA 700 RED [A2016XAT4EUSR] - 2016 года выпуска

  • №
    Артикул
    Название
  • 1
    4406-934 SHROUD, SPLASH
    SHROUD, SPLASH
  • 2
    1423-276 RIVET, REINSTALLABLE
    RIVET, REINSTALLABLE
  • 3
    1470-090 DUCT, INTAKE - TOP/AIR IN-BELT COOLING
    DUCT, INTAKE - TOP/AIR IN-BELT COOLING
  • 4
    1470-089 DUCT, INTAKE - TOP
    DUCT, INTAKE - TOP
  • 5
    0423-019 CLAMP
    CLAMP
  • 6
    1470-097 DUCT, INTAKE - DIVERTER/HOUSING
    DUCT, INTAKE - DIVERTER/HOUSING
  • 7
    0570-403 HOUSING, INTAKE
    HOUSING, INTAKE
  • 8
    0423-066 CLAMP
    CLAMP
  • 9
    1470-047 DUCT, INTAKE - HOUSING/THROTTLE BODY
    DUCT, INTAKE - HOUSING/THROTTLE BODY
  • 10
    0470-891 FILTER, VENT
    FILTER, VENT
  • 11
    1623-101 CLAMP, HOSE
    CLAMP, HOSE
  • 12
    1470-078 FILTER, AIR
    FILTER, AIR
  • 13
    1470-039 SEAL
    SEAL
  • 14
    0570-405 COVER, INTAKE
    COVER, INTAKE
  • 15
    0423-455 CLIP, SPRING
    CLIP, SPRING
  • 16
    1423-278 CLAMP
    CLAMP
  • 17
    0423-766 CAP, DRAIN
    CAP, DRAIN
  • 18
    1623-282 CLAMP, HOSE
    CLAMP, HOSE
  • 19
    0410-318 HOSE, VENT
    HOSE, VENT
  • 20
    1619-453 CONDUIT, HIGH TEMPERATURE - 37"
    CONDUIT, HIGH TEMPERATURE - 37"
  • 21
    1623-740 TIE, CABLE - 15 IN.
    TIE, CABLE - 15 IN.
