FRONT SUSPENSION ASSEMBLY для Arctic Cat ALTERRA 550 [A2016XAO4EUSR] - 2016 года выпуска

  • №
    Артикул
    Название
  • 1
    0403-420 SHOCK ABSORBER
    SHOCK ABSORBER
  • 2
    0403-395 CAM, ADJUSTER - SPRING
    CAM, ADJUSTER - SPRING
  • 3
    0503-882 SPRING, SUSPENSION - WHITE
    SPRING, SUSPENSION - WHITE
  • 4
    1603-889 RETAINER, SPRING
    RETAINER, SPRING
  • 5
    8409-045 SCREW, CAP
    SCREW, CAP
  • 6
    0423-744 NUT, LOCK
    NUT, LOCK
  • 7
    0503-870 A-ARM, UPPER RIGHT - BLACK (INC. TWO NO. 8, ONE NO. 9, AND TWO NO. 10-11)
    A-ARM, UPPER RIGHT - BLACK (INC. TWO NO. 8, ONE NO. 9, AND TWO NO. 10-11)
  • 7
    0503-871 A-ARM, UPPER LEFT - BLACK (INC. TWO NO. 8, ONE NO. 9, AND TWO NO. 10-11)
    A-ARM, UPPER LEFT - BLACK (INC. TWO NO. 8, ONE NO. 9, AND TWO NO. 10-11)
  • 8
    0403-289 ...BUSHING, UPPER A-ARM SUSPENSION
    ...BUSHING, UPPER A-ARM SUSPENSION
  • 9
    0403-439 ...AXLE
    ...AXLE
  • 10
    0423-009 ...CLIP, BALL JOINT
    ...CLIP, BALL JOINT
  • 11
    0405-483 ...BALL JOINT
    ...BALL JOINT
  • 12
    0423-334 SCREW, CAP
    SCREW, CAP
  • 13
    0503-868 A-ARM, LOWER RIGHT - BLACK (INC. TWO NO. 10-11, FOUR NO. 14, AND TWO NO. 15)
    A-ARM, LOWER RIGHT - BLACK (INC. TWO NO. 10-11, FOUR NO. 14, AND TWO NO. 15)
  • 13
    0503-869 A-ARM, LOWER LEFT - BLACK (INC. TWO NO. 10-11, FOUR NO. 14, AND TWO NO. 15)
    A-ARM, LOWER LEFT - BLACK (INC. TWO NO. 10-11, FOUR NO. 14, AND TWO NO. 15)
  • 14
    0403-409 ...BUSHING
    ...BUSHING
  • 15
    0403-438 ...COLLAR
    ...COLLAR
  • 16
    8409-075 SCREW, CAP
    SCREW, CAP
  • 17
    2502-351 KIT, HALFSHAFT (INC. 18-20)
    KIT, HALFSHAFT (INC. 18-20)
  • 18
    2436-111 ...REPAIR KIT, BOOT (INC. 19)
    ...REPAIR KIT, BOOT (INC. 19)
  • 19
    1441-988 ......CLIP, RETAINING
    ......CLIP, RETAINING
  • 20
    1402-885 ...PIN, DETENT
    ...PIN, DETENT
  • 21
    1402-889 ...CLIP, RETAINING
    ...CLIP, RETAINING
  • 22
    0503-880 KNUCKLE - ASSEMBLY - RIGHT (INC. ONE NO. 23-24)
    KNUCKLE - ASSEMBLY - RIGHT (INC. ONE NO. 23-24)
  • 22
    0503-881 KNUCKLE - ASSEMBLY - LEFT (INC. ONE NO. 23-24)
    KNUCKLE - ASSEMBLY - LEFT (INC. ONE NO. 23-24)
  • 23
    1402-809 ...BEARING
    ...BEARING
  • 24
    0423-423 ...RING, RETAINING
    ...RING, RETAINING
  • 25
    0423-998 SCREW, SHOULDER
    SCREW, SHOULDER
  • 26
    7506-033 BRACE, A-ARM - BLACK
    BRACE, A-ARM - BLACK
  • 27
    4406-714 GUARD, BOOT - RIGHT - BLACK
    GUARD, BOOT - RIGHT - BLACK
  • 27
    4406-715 GUARD, BOOT - LEFT - BLACK
    GUARD, BOOT - LEFT - BLACK
  • 28
    1423-109 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
