HYDRAULIC BRAKE ASSEMBLY для Arctic Cat ALTERRA 450 RED [ACA2016KAK4CUSG] - 2016 года выпуска

  • №
    Артикул
    Название
  • 1
    3307-069 BOLT FLANGE 8X20
    BOLT FLANGE 8X20
  • 2
    3323-230 CALIPER, BRAKE (RIGHT FRONT) (INC. 3-9)
    CALIPER, BRAKE (RIGHT FRONT) (INC. 3-9)
  • 2
    3323-231 CALIPER, BRAKE (FRONT LEFT & REAR RIGHT) (INC. 3-9)
    CALIPER, BRAKE (FRONT LEFT & REAR RIGHT) (INC. 3-9)
  • 3
    1436-160 ...HOUSING, CALIPER - ASSEMBLY (RIGHT FRONT) (INC. 4-6)
    ...HOUSING, CALIPER - ASSEMBLY (RIGHT FRONT) (INC. 4-6)
  • 3
    1436-161 ...HOUSING, CALIPER - ASSEMBLY (FRONT LEFT & REAR RIGHT) (INC. 4-6)
    ...HOUSING, CALIPER - ASSEMBLY (FRONT LEFT & REAR RIGHT) (INC. 4-6)
  • 4
    0502-606 ......PISTON/SEAL SET (INC. 5)
    ......PISTON/SEAL SET (INC. 5)
  • 5
    0502-607 .........SEAL SET
    .........SEAL SET
  • 6
    0502-609 ......VALVE, BLEED
    ......VALVE, BLEED
  • 7
    0502-608 ...O-RING, GUIDE - SET
    ...O-RING, GUIDE - SET
  • 8
    0502-605 ...BRACKET ASSEMBLY
    ...BRACKET ASSEMBLY
  • 9
    1436-420 ...PAD, BRAKE - SET
    ...PAD, BRAKE - SET
  • 10
    3307-067 BOLT, BANJO-FITTING
    BOLT, BANJO-FITTING
  • 11
    3303-284 WASHER, CRUSH
    WASHER, CRUSH
  • 12
    3303-919 CLAMP, BRAKE HOSE
    CLAMP, BRAKE HOSE
  • 13
    3304-553 BOLT, FLANGE - 6 X 12
    BOLT, FLANGE - 6 X 12
  • 14
    3313-523 BRACKET, MOUNTING - BRAKE HOSE ASSEMBLY
    BRACKET, MOUNTING - BRAKE HOSE ASSEMBLY
  • 15
    3305-789 BOLT FLANGE 6X30 (G)
    BOLT FLANGE 6X30 (G)
  • 16
    3313-750 HOSE (JUNCTION), BRAKE - ASSEMBLY
    HOSE (JUNCTION), BRAKE - ASSEMBLY
  • 17
    3313-422 HOSE, BRAKE
    HOSE, BRAKE
  • 18
    3313-316 CYLINDER, MASTER BRAKE - ASSEMBLY (INC. 19-26)
    CYLINDER, MASTER BRAKE - ASSEMBLY (INC. 19-26)
  • 19
    0502-566 ...SCREW, MACHINE
    ...SCREW, MACHINE
  • 20
    0502-868 ...COVER, RESERVOIR
    ...COVER, RESERVOIR
  • 21
    0502-568 ...SCREW, MACHINE
    ...SCREW, MACHINE
  • 22
    0502-869 ...CLAMP, HANDLEBAR
    ...CLAMP, HANDLEBAR
  • 23
    0502-704 ...MASTER CYLINDER ASSEMBLY
    ...MASTER CYLINDER ASSEMBLY
  • 24
    1502-904 ...LEVER ASSEMBLY - KIT (INC. 25-26)
    ...LEVER ASSEMBLY - KIT (INC. 25-26)
  • 25
    1502-905 ......LOCK, BRAKE LEVER - KIT
    ......LOCK, BRAKE LEVER - KIT
  • 26
    0502-580 ......LEVER PIN - KIT
    ......LEVER PIN - KIT
  • 27
    3313-423 HOSE, BRAKE
    HOSE, BRAKE
  • 28
    3304-674 BOLT, OIL - 10 X 33
    BOLT, OIL - 10 X 33
  • 29
    3313-478 BRAKE ASSEMBLY (INC. 30-32)
    BRAKE ASSEMBLY (INC. 30-32)
  • 30
    1502-141 ...RESERVOIR, BRAKE - W/CLAMP
    ...RESERVOIR, BRAKE - W/CLAMP
  • 31
    3313-489 ...HOSE, BRAKE FLUID RESERVOIR - W/CLAMPS
    ...HOSE, BRAKE FLUID RESERVOIR - W/CLAMPS
  • 32
    1502-296 ...HOSE ADAPTER SPOUT, 90-DEGREE - GROMMET SEAL
    ...HOSE ADAPTER SPOUT, 90-DEGREE - GROMMET SEAL
  • 33
    3304-061 NUT CLIP 5 MM
    NUT CLIP 5 MM
  • 34
    3306-146 BOLT-WASH 5X22
    BOLT-WASH 5X22
  • 35
    3313-820 SWITCH, BRAKE
    SWITCH, BRAKE
  • 36
    3313-315 HOSE, BRAKE
    HOSE, BRAKE
  • 37
    0123-788 TIE, CABLE - 8 IN.
    TIE, CABLE - 8 IN.
  • 38
    3303-386 BOLT, FLANGE
    BOLT, FLANGE
  • 39
    1602-213 O-RING
    O-RING
  • 40
    3313-156 LEVER, BRAKE - BLACK
    LEVER, BRAKE - BLACK
  • 41
    3304-138 WASHER
    WASHER
  • 42
    3304-543 BOLT FLANGE 8X16
    BOLT FLANGE 8X16
