WIRING HARNESS ASSEMBLY для Arctic Cat 700 TBX RED [A2015BBT1PUSR] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    0486-485 HARNESS, MAIN (INC. 2-10)
    HARNESS, MAIN (INC. 2-10)
  • 2
    0486-164 ...TETHER, ACCESSORY CONNECTOR
    ...TETHER, ACCESSORY CONNECTOR
  • 3
    0430-085 ...COVER, FUSE BLOCK
    ...COVER, FUSE BLOCK
  • 4
    0430-045 ...RELAY (4-PIN) - 20 AMP
    ...RELAY (4-PIN) - 20 AMP
  • 5
    0430-033 ...RELAY (5-PIN) - 30 AMP
    ...RELAY (5-PIN) - 30 AMP
  • 6
    0430-037 ...HOLDER, FUSE
    ...HOLDER, FUSE
  • 7
    0430-032 ...FUSE - 10 AMP
    ...FUSE - 10 AMP
  • 7
    0430-031 ...FUSE - 15 AMP
    ...FUSE - 15 AMP
  • 7
    0430-030 ...FUSE - 30 AMP
    ...FUSE - 30 AMP
  • 8
    3411-968 ...DECAL, FUSE BLOCK
    ...DECAL, FUSE BLOCK
  • 9
    0430-086 ...SEAL
    ...SEAL
  • 10
    0430-103 ...COVER, DIAGNOSTICS CONNECTOR
    ...COVER, DIAGNOSTICS CONNECTOR
  • 11
    1436-416 REPAIR KIT, CONNECTOR - TILT SENSOR
    REPAIR KIT, CONNECTOR - TILT SENSOR
  • 12
    0437-071 REPAIR KIT, CONNECTOR - IDLE SPEED CONTROL
    REPAIR KIT, CONNECTOR - IDLE SPEED CONTROL
  • 13
    1436-818 REPAIR KIT, CONNECTOR - CAN GAUGE
    REPAIR KIT, CONNECTOR - CAN GAUGE
  • 14
    1436-289 REPAIR KIT, CONNECTOR - HEADLIGHT
    REPAIR KIT, CONNECTOR - HEADLIGHT
  • 15
    1436-483 REPAIR KIT, 3P MAP CONNECTOR
    REPAIR KIT, 3P MAP CONNECTOR
  • 16
    4406-029 BRACKET, MOUNTING - COIL
    BRACKET, MOUNTING - COIL
  • 17
    8476-620 SCREW, MACHINE
    SCREW, MACHINE
  • 18
    0824-071 COIL, IGNITION - ASSEMBLY (INC. 19)
    COIL, IGNITION - ASSEMBLY (INC. 19)
  • 19
    0824-049 ...CAP, SPARK PLUG
    ...CAP, SPARK PLUG
  • 20
    8468-425 SCREW, MACHINE
    SCREW, MACHINE
  • 21
    0423-493 NUT W/WASHER
    NUT W/WASHER
  • 22
    0623-038 NUT W/WASHER
    NUT W/WASHER
  • 23
    0824-078 REGULATOR, VOLTAGE
    REGULATOR, VOLTAGE
  • 24
    8476-625 SCREW, MACHINE
    SCREW, MACHINE
  • 25
    0409-064 SENSOR, TILT
    SENSOR, TILT
  • 26
    0123-802 WASHER
    WASHER
  • 27
    0623-785 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 28
    0409-089 SWITCH, BRAKE - ASSEMBLY
    SWITCH, BRAKE - ASSEMBLY
  • 29
    0530-121 ECM
    ECM
  • 30
    0623-362 CLIP, RETAINING
    CLIP, RETAINING
  • 31
    2416-181 TRAY, ELECTRICAL
    TRAY, ELECTRICAL
  • 32
    0123-788 TIE, CABLE - 8 IN.
    TIE, CABLE - 8 IN.
  • 32
    0123-903 TIE, CABLE - 11.5 IN.
    TIE, CABLE - 11.5 IN.
