REAR SUSPENSION ASSEMBLY для Arctic Cat 450 Core EFT - 2013 года выпуска`
-
№АртикулНазвание
-
13313-541 SHOCK/SPRING ASSEMBLY - PLATINUMSHOCK/SPRING ASSEMBLY - PLATINUM
-
23303-376 SCREW, CAPSCREW, CAP
-
33304-031 NUT, LOCKNUT, LOCK
-
48409-065 SCREW, CAPSCREW, CAP
-
53306-414 A-ARM, UPPER RIGHT - PLATINUM (INC. 6-8)A-ARM, UPPER RIGHT - PLATINUM (INC. 6-8)
-
53306-415 A-ARM, UPPER LEFT - PLATINUM (INC. 6-8)A-ARM, UPPER LEFT - PLATINUM (INC. 6-8)
-
63313-111 ...AXLE...AXLE
-
73313-112 ...BUSHING...BUSHING
-
83313-113 ...SEAL...SEAL
-
93323-188 SCREW, CAPSCREW, CAP
-
103313-430 SCREW, CAPSCREW, CAP
-
113304-183 SCREW, CAPSCREW, CAP
-
123313-134 A-ARM, LOWER RIGHT - PLATINUM (INC. 7-8 AND 13)A-ARM, LOWER RIGHT - PLATINUM (INC. 7-8 AND 13)
-
123313-135 A-ARM, LOWER LEFT - PLATINUM (INC. 7-8 AND 13)A-ARM, LOWER LEFT - PLATINUM (INC. 7-8 AND 13)
-
133313-107 ...AXLE...AXLE
-
143313-832 AXLE, DRIVE (INC. 15-17)AXLE, DRIVE (INC. 15-17)
-
153313-560 ...REPAIR KIT, BOOT - DRIVE AXLE - INBOUND...REPAIR KIT, BOOT - DRIVE AXLE - INBOUND
-
160423-845 ......RING, RETAINING......RING, RETAINING
-
173313-558 ...REPAIR KIT, BOOT - DRIVE AXLE - OUTBOUND...REPAIR KIT, BOOT - DRIVE AXLE - OUTBOUND
-
183323-108 KNUCKLE - ASSEMBLY - RIGHT (INC. 19-22)KNUCKLE - ASSEMBLY - RIGHT (INC. 19-22)
-
183323-109 KNUCKLE - ASSEMBLY - LEFT (INC. 19-22)KNUCKLE - ASSEMBLY - LEFT (INC. 19-22)
-
191402-809 ...BEARING...BEARING
-
200423-423 ...RING, RETAINING...RING, RETAINING
-
210403-206 ...BUSHING...BUSHING
-
220403-213 ...AXLE...AXLE
