WIRING HARNESS ASSEMBLY для Arctic Cat 400 TRV RED [A2011TBG4BUSR] - 2011 года выпуска

  • №
    Артикул
    Название
  • 1
    0486-325 HARNESS, MAIN (INC. 2-8)
    HARNESS, MAIN (INC. 2-8)
  • 2
    0486-164 ...TETHER, ACCESSORY CONNECTOR
    ...TETHER, ACCESSORY CONNECTOR
  • 3
    0430-085 ...COVER, FUSE BLOCK
    ...COVER, FUSE BLOCK
  • 4
    0430-045 ...RELAY (4-PIN) - 20 AMP
    ...RELAY (4-PIN) - 20 AMP
  • 5
    0430-032 ...FUSE - 10 AMP
    ...FUSE - 10 AMP
  • 5
    0430-031 ...FUSE - 15 AMP
    ...FUSE - 15 AMP
  • 5
    0430-030 ...FUSE - 30 AMP
    ...FUSE - 30 AMP
  • 6
    0430-037 ...HOLDER, FUSE
    ...HOLDER, FUSE
  • 7
    0430-086 ...SEAL
    ...SEAL
  • 8
    2411-078 ...DECAL, FUSE BLOCK
    ...DECAL, FUSE BLOCK
  • 9
    0123-788 TIE, CABLE - 8 IN.
    TIE, CABLE - 8 IN.
  • 10
    0445-053 CABLE, SOLENOID/STARTER (INC. 11)
    CABLE, SOLENOID/STARTER (INC. 11)
  • 11
    0645-019 ...BOOT, TERMINAL
    ...BOOT, TERMINAL
  • 12
    0645-327 BOOT, TERMINAL
    BOOT, TERMINAL
  • 13
    0445-055 CABLE, BATTERY/SOLENOID
    CABLE, BATTERY/SOLENOID
  • 14
    0623-038 NUT W/WASHER
    NUT W/WASHER
  • 15
    0445-058 SOLENOID
    SOLENOID
  • 16
    8476-625 SCREW, MACHINE
    SCREW, MACHINE
  • 17
    0412-291 FOIL, PROTECTIVE
    FOIL, PROTECTIVE
  • 18
    1406-787 TRAY, ELECTRICAL
    TRAY, ELECTRICAL
  • 19
    0623-362 RIVET, REINSTALLABLE
    RIVET, REINSTALLABLE
  • 20
    3313-436 CDI UNIT
    CDI UNIT
  • 21
    0409-089 SWITCH, BRAKE - ASSEMBLY
    SWITCH, BRAKE - ASSEMBLY
  • 22
    0123-903 CABLE TIE - 11.5 IN.
    CABLE TIE - 11.5 IN.
  • 23
    0824-037 REGULATOR, VOLTAGE
    REGULATOR, VOLTAGE
  • 24
    0445-054 CABLE, BATTERY/GROUND
    CABLE, BATTERY/GROUND
  • 25
    3323-216 COIL, IGNITION - ASSEMBLY (INC. 26)
    COIL, IGNITION - ASSEMBLY (INC. 26)
  • 26
    3313-695 ...CAP, SPARK PLUG
    ...CAP, SPARK PLUG
  • 27
    8470-525 SCREW, MACHINE
    SCREW, MACHINE
  • 28
    8427-502 NUT, LOCK
    NUT, LOCK
