AIR INTAKE ASSEMBLY для Arctic Cat TRV 1000 H2 EFI (Metallic Black) [A2010TBW4EUSO] - 2010 года выпуска`
-
№АртикулНазвание
-
10413-091 DIVERTER, AIR - TOPDIVERTER, AIR - TOP
-
20413-093 DIVERTER, AIR - BOTTOMDIVERTER, AIR - BOTTOM
-
32406-509 SHROUD, SPLASHSHROUD, SPLASH
-
40623-362 RIVET, REINSTALLABLERIVET, REINSTALLABLE
-
50423-551 CLAMPCLAMP
-
60423-342 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
70413-096 CAP, AIR INTAKE - DIVERTERCAP, AIR INTAKE - DIVERTER
-
80470-583 BOOT, AIR INTAKEBOOT, AIR INTAKE
-
90423-019 CLAMP, HOSE-WORM (NORMA 50-70)CLAMP, HOSE-WORM (NORMA 50-70)
-
100423-716 WING NUTWING NUT
-
110470-832 COVER, AIR INTAKECOVER, AIR INTAKE
-
120470-828 FILTER, AIRFILTER, AIR
-
130470-731 SUPPORT, AIR FILTERSUPPORT, AIR FILTER
-
140570-221 HOUSING, AIR INTAKEHOUSING, AIR INTAKE
-
150406-877 BUMPERBUMPER
-
160470-442 VALVE, DRAINVALVE, DRAIN
-
170470-638 BOOT, THROTTLE BODYBOOT, THROTTLE BODY
-
180430-055 SENSOR, AIR TEMPERATURE (INC. 19)SENSOR, AIR TEMPERATURE (INC. 19)
-
195507-224 ...O-RING...O-RING
-
200623-028 CLAMP, HOSECLAMP, HOSE
-
210410-198 HOSE, SEPARATOR TANKHOSE, SEPARATOR TANK
-
220470-718 TANK, SEPARATORTANK, SEPARATOR
-
230410-196 HOSE, CRANKCASEHOSE, CRANKCASE
-
240410-208 HOSE, CRANKCASEHOSE, CRANKCASE
-
250423-066 CLAMP, HOSE-WORM 50MMX9MM (40-60 NORMA)CLAMP, HOSE-WORM 50MMX9MM (40-60 NORMA)
