TUNNEL ASSEMBLY W/ LOWER NOSEPAN для Yamaha SRX 120 R - 2019 года выпуска`
-
№АртикулНазвание
-
18MV-F1910-00-00 FRAME COMP.FRAME COMP.
-
28MV-F191A-00-00 ...BULKHEAD...BULKHEAD
-
38JP-RA514-00-00 ...RIVET, 5 (UN)...RIVET, 5 (UN)
-
48JM-F1943-00-00 ...BRACKET, MAIN TRACK 1 (RIGHT HAND)...BRACKET, MAIN TRACK 1 (RIGHT HAND)
-
58JM-F1953-00-00 ...BRACKET, MAIN TRACK 2 (LEFT HAND)...BRACKET, MAIN TRACK 2 (LEFT HAND)
-
68JM-F1923-00-00 REINEFORCEMENT, FRAME REAR 1REINEFORCEMENT, FRAME REAR 1
-
78JM-RA202-00-00 SCREW, TAPPINGSCREW, TAPPING
-
88ML-F191D-00-00 FRAME, FRONT ENDFRAME, FRONT END
-
98JP-F15B3-00-00 TRIM (3 FEET) (UN)TRIM (3 FEET) (UN)
-
108JM-RA138-00-00 BOLT, FLANGEBOLT, FLANGE
-
118JM-H1910-00-00 VOLTAGE REGULATOR ASSYVOLTAGE REGULATOR ASSY
-
128JP-RA357-00-00 NUT, SELF-LOCKINGNUT, SELF-LOCKING
-
138JM-RA106-00-00 BOLT, FLANGEBOLT, FLANGE
-
148JM-F1931-00-00 REINFORCEMENT, FRAME FRONT 2 (RIGHT HAND)REINFORCEMENT, FRAME FRONT 2 (RIGHT HAND)
-
158JM-F1921-00-00 REINEFORCEMENT, FRAME REAR 1 (LEFT HAND)REINEFORCEMENT, FRAME REAR 1 (LEFT HAND)
-
168JM-F7421-00-00 FOOTREST 2 (RIGHT HAND)FOOTREST 2 (RIGHT HAND)
-
178JM-F7411-00-00 FOOTREST 1 (LEFT HAND)FOOTREST 1 (LEFT HAND)
-
188JP-RA515-00-00 RIVET, 6RIVET, 6
-
198JM-E3327-00-00 COVER, PUMP GEARCOVER, PUMP GEAR
-
208JM-RAB01-00-00 CLAMP, 2 (8 INCH) (UN)CLAMP, 2 (8 INCH) (UN)
-
218JM-F192E-00-00 REINFORCEMENT, FRAME (RIGHT HAND)REINFORCEMENT, FRAME (RIGHT HAND)
-
228JM-F1929-00-00 REINFORCEMENT, FRAME SIDE (LEFT HAND)REINFORCEMENT, FRAME SIDE (LEFT HAND)
-
238JM-K7544-00-00 BUMPER, REAR 4 (RIGHT HAND)BUMPER, REAR 4 (RIGHT HAND)
-
248JM-K7543-00-00 BUMPER, REAR 3 (LEFT HAND)BUMPER, REAR 3 (LEFT HAND)
-
258JP-RA518-00-00 RIVET, 9RIVET, 9
-
268JM-RA601-00-00 PLUG, 2PLUG, 2
-
278JP-F151A-00-00 LABEL 1LABEL 1
-
288JM-K7762-00-00 LABEL, WARNING 2LABEL, WARNING 2
-
298JM-K7541-00-00 BUMPER, REAR 1BUMPER, REAR 1
-
308JM-RA411-00-00 WASHER, PLAINWASHER, PLAIN
-
318JM-K7595-00-00 FLAPFLAP
-
328JP-RA519-00-00 RIVET, 10RIVET, 10
-
338JM-RAY04-01-00 FLAG ASSY.FLAG ASSY.
-
348JM-RA403-00-00 WASHER, PLAINWASHER, PLAIN
-
358JM-RA104-00-00 BOLT, FLANGEBOLT, FLANGE
-
368JM-RA203-00-00 SCREW, TAPPINGSCREW, TAPPING
-
378MV-F198G-00-00 COVER 2 (RIGHT HAND)COVER 2 (RIGHT HAND)
-
388MV-F198F-00-00 COVER 1 (LEFT HAND)COVER 1 (LEFT HAND)
-
398MV-F196G-00-00 BRACKET 4 (RIGHT HAND)BRACKET 4 (RIGHT HAND)
-
408MV-F196F-00-00 BRACKET 3 (LEFT HAND)BRACKET 3 (LEFT HAND)
-
418MV-F191B-00-00 PLATE 1PLATE 1
-
428MV-F376J-00-00 HOLDER, ABSORBERHOLDER, ABSORBER
-
438JM-RA117-00-00 BOLT, FLANGEBOLT, FLANGE
-
448JM-RA303-00-00 NUT, SELF-LOCKINGNUT, SELF-LOCKING
-
458JM-H2551-00-00 STOP SWITCH ASSYSTOP SWITCH ASSY
-
468JM-H2552-00-00 ...CAP, SWITCH...CAP, SWITCH
-
478JM-G2148-00-00 RETAINER, SPRINGRETAINER, SPRING
-
488MV-E417F-00-00 LABEL, CAUTIONLABEL, CAUTION
-
498JM-G7465-00-00 SHAFT 1SHAFT 1
-
508MV-RA466-00-00 WASHER, 9WASHER, 9
-
518MV-K7511-00-00 BUMPER, FRONT 1BUMPER, FRONT 1
-
528MV-RA106-00-00 BOLT, FLANGEBOLT, FLANGE
-
538JM-RAB01-10-00 CLAMP, 2CLAMP, 2
