HANDLEBAR - SWITCHES AND LEVERS для Yamaha APEX GT - 2006 года выпуска`
-
№АртикулНазвание
-
18FP-82720-00-00 LEVER HOLDER ASSY (RIGHT)LEVER HOLDER ASSY (RIGHT)
-
28R6-8399F-00-00 ...SHAFT...SHAFT
-
399001-04600-00 ...CIRCLIP...CIRCLIP
-
48FP-82970-00-00 ...THUMB WARMER ASSY...THUMB WARMER ASSY
-
58FP-83973-00-00 SWITCH, HANDLE 3SWITCH, HANDLE 3
-
698507-05016-00 SCREW, PAN HEADSCREW, PAN HEAD
