HANDLEBAR PAD W/ STEERING GATE для Yamaha VENTURE 700 - 2001 года выпуска`
-
№АртикулНазвание
-
18CR-23870-10-00 STEERING GATE COMP.STEERING GATE COMP.
-
295827-08016-00 BOLT, FLANGEBOLT, FLANGE
-
38DF-23867-00-00 HOLDER 2HOLDER 2
-
490267-48095-00 RIVET, BLINDRIVET, BLIND
-
58DN-23882-00-00 BRACKET 2 (VT700F)BRACKET 2 (VT700F)
-
68CR-23881-00-00 BRACKET 1 (VT700F)BRACKET 1 (VT700F)
-
68CR-23881-00-00 BRACKET 1 (VT600F)BRACKET 1 (VT600F)
-
795827-06016-00 BOLT, FLANGE (VT700F)BOLT, FLANGE (VT700F)
-
795827-06016-00 BOLT, FLANGE (VT600F)BOLT, FLANGE (VT600F)
-
890105-060A6-00 BOLT, WASHER BASED (VT700F)BOLT, WASHER BASED (VT700F)
-
98CR-23815-20-00 PAD, STEERINGPAD, STEERING
