ELECTRICAL - INSTRUMENTS для Yamaha BRAVO 250 - 2000 года выпуска
-
№АртикулНазвание
-
280V-83510-40-00 SPEEDOMETER ASSEMBLY (MILE/H) (UR)SPEEDOMETER ASSEMBLY (MILE/H) (UR)
-
28V7-83536-40-00 ...SOCKET, METER...SOCKET, METER
-
34R0-83517-00-00 ...BULB (12V-3.4W T10)...BULB (12V-3.4W T10)
-
48G6-83523-00-00 ...DAMPER...DAMPER
-
595307-05600-00 ...NUT...NUT
-
692907-05100-00 ...WASHER, SPRING...WASHER, SPRING
-
78Y8-83550-00-00 SPEEDOMETER CABLE ASSEMBLYSPEEDOMETER CABLE ASSEMBLY
-
88Y1-47700-00-00 METER GEAR HOUSING COMPMETER GEAR HOUSING COMP
-
98K4-47715-00-00 JOINTJOINT
