COWLING - SIDE для Yamaha YZFR6 - 2018 года выпуска
-
№АртикулНазвание
-
1BN6-2117V-00-P0 COVER 7 (DPBMC - DEEP PURPLISH BLUE)COVER 7 (DPBMC - DEEP PURPLISH BLUE)
-
1BN6-2117V-00-P3 COVER 7 (MNM3 - MAT GRAY)COVER 7 (MNM3 - MAT GRAY)
-
1BN6-W217V-20-P2 COVER ASSY 7 (BWP1 - BLUISH WHITE)COVER ASSY 7 (BWP1 - BLUISH WHITE)
-
2BN6-28398-20-00 ...GRAPHIC 5 (BWP1 - BLUISH WHITE)...GRAPHIC 5 (BWP1 - BLUISH WHITE)
-
390520-30002-00 DAMPER, PLATEDAMPER, PLATE
-
47CH-22889-00-00 SEAL 12SEAL 12
-
590480-12613-00 GROMMETGROMMET
-
690387-067K8-00 COLLARCOLLAR
-
790201-07081-00 WASHER, PLATEWASHER, PLATE
-
890111-06063-00 BOLT, HEX. SOCKET BUTTONBOLT, HEX. SOCKET BUTTON
-
990111-05045-00 BOLT, HEX. SOCKET BUTTONBOLT, HEX. SOCKET BUTTON
-
1090183-060A6-00 NUT, SPRINGNUT, SPRING
-
1190464-07018-00 CLAMPCLAMP
-
1290149-06298-00 SCREWSCREW
-
1390201-060H9-00 WASHER, PLATEWASHER, PLATE
-
1490468-04001-00 CLIPCLIP
-
15BN6-2117W-00-P0 COVER 8 (DPBMC - DEEP PURPLISH BLUE)COVER 8 (DPBMC - DEEP PURPLISH BLUE)
-
15BN6-2117W-00-P3 COVER 8 (MNM3 - MAT GRAY)COVER 8 (MNM3 - MAT GRAY)
-
15BN6-W217W-20-P2 COVER ASSY 8 (BWP1 - BLUISH WHITE)COVER ASSY 8 (BWP1 - BLUISH WHITE)
-
16BN6-28399-20-00 ...GRAPHIC 6 (BWP1 - BLUISH WHITE)...GRAPHIC 6 (BWP1 - BLUISH WHITE)
-
1790520-60001-00 DAMPER, PLATEDAMPER, PLATE
-
1890520-30008-00 DAMPER, PLATEDAMPER, PLATE
-
197CH-2289T-00-00 SEAL 26SEAL 26
-
2090480-12613-00 GROMMETGROMMET
-
2190387-067K8-00 COLLARCOLLAR
-
2290201-07081-00 WASHER, PLATEWASHER, PLATE
-
2390111-06063-00 BOLT, HEX. SOCKET BUTTONBOLT, HEX. SOCKET BUTTON
-
2490111-05045-00 BOLT, HEX. SOCKET BUTTONBOLT, HEX. SOCKET BUTTON
-
2590183-060A6-00 NUT, SPRINGNUT, SPRING
-
2690464-07018-00 CLAMPCLAMP
-
2790149-06298-00 SCREWSCREW
-
2890201-060H9-00 WASHER, PLATEWASHER, PLATE
-
2990468-04001-00 CLIPCLIP
-
30BN6-28385-00-P0 COVER, UNDER (BWP1 - BLUISH WHITE)COVER, UNDER (BWP1 - BLUISH WHITE)
-
30BN6-28385-00-P1 COVER, UNDER (DPBMC - DEEP PURPLISH BLUE)COVER, UNDER (DPBMC - DEEP PURPLISH BLUE)
-
30BN6-28385-00-P2 COVER, UNDER (MNM3 - MAT GRAY)COVER, UNDER (MNM3 - MAT GRAY)
-
3199244-00180-00 EMBLEM, YAMAHA (MNM3 - MAT GRAY)EMBLEM, YAMAHA (MNM3 - MAT GRAY)
-
3290183-05076-00 NUT, SPRINGNUT, SPRING
-
3390480-14003-00 GROMMETGROMMET
-
3490387-06260-00 COLLARCOLLAR
-
3590111-06040-00 BOLT, HEX. SOCKET BUTTONBOLT, HEX. SOCKET BUTTON
-
36BN6-2838G-00-00 SEAT 1SEAT 1
-
37BN6-2836T-00-00 DAMPER, LOCATING 1DAMPER, LOCATING 1
-
38BN6-W283U-30-P0 PANEL ASSY 1 (DPBMC - DEEP PURPLISH BLUE)PANEL ASSY 1 (DPBMC - DEEP PURPLISH BLUE)
-
38BN6-W283U-40-P3 PANEL ASSY 1 (MNM3 - MAT GRAY)PANEL ASSY 1 (MNM3 - MAT GRAY)
-
38BN6-W283U-50-P2 PANEL ASSY 1 (BWP1 - BLUISH WHITE)PANEL ASSY 1 (BWP1 - BLUISH WHITE)
-
39BN6-28391-20-00 ...GRAPHIC 1 (DPBMC - DEEP PURPLISH BLUE)...GRAPHIC 1 (DPBMC - DEEP PURPLISH BLUE)
-
40BN6-28391-30-00 ...GRAPHIC 1 (MNM3 - MAT GRAY)...GRAPHIC 1 (MNM3 - MAT GRAY)
-
41BN6-28391-40-00 ...GRAPHIC 1 (BWP1 - BLUISH WHITE)...GRAPHIC 1 (BWP1 - BLUISH WHITE)
-
4290480-14003-00 GROMMETGROMMET
-
4390387-06260-00 COLLARCOLLAR
-
4490111-06040-00 BOLT, HEX. SOCKET BUTTONBOLT, HEX. SOCKET BUTTON
-
4590183-05076-00 NUT, SPRINGNUT, SPRING
-
4690111-05045-00 BOLT, HEX. SOCKET BUTTONBOLT, HEX. SOCKET BUTTON
-
4790269-06046-00 RIVETRIVET
-
48BN6-28416-00-00 DAMPER 2DAMPER 2
-
495YT-24665-00-00 DAMPERDAMPER
-
5090520-20013-00 DAMPER, PLATEDAMPER, PLATE
-
51BN6-28219-00-00 COVER 1COVER 1
-
5290111-05045-00 BOLT, HEX. SOCKET BUTTONBOLT, HEX. SOCKET BUTTON
-
53BN6-28395-00-P0 COVER, UNDER 2 (BWP1 - BLUISH WHITE)COVER, UNDER 2 (BWP1 - BLUISH WHITE)
-
53BN6-28395-00-P1 COVER, UNDER 2 (DPBMC - DEEP PURPLISH BLUE)COVER, UNDER 2 (DPBMC - DEEP PURPLISH BLUE)
-
53BN6-28395-00-P2 COVER, UNDER 2 (MNM3 - MAT GRAY)COVER, UNDER 2 (MNM3 - MAT GRAY)
-
5499244-00180-00 EMBLEM, YAMAHA (MNM3 - MAT GRAY)EMBLEM, YAMAHA (MNM3 - MAT GRAY)
-
5590183-05076-00 NUT, SPRINGNUT, SPRING
-
5690480-14003-00 GROMMETGROMMET
-
5790387-06260-00 COLLARCOLLAR
-
5890111-06040-00 BOLT, HEX. SOCKET BUTTONBOLT, HEX. SOCKET BUTTON
-
59BN6-2848K-00-00 SEAT 2SEAT 2
-
6090111-05045-00 BOLT, HEX. SOCKET BUTTONBOLT, HEX. SOCKET BUTTON
-
61BN6-W283V-30-P0 PANEL ASSY 2 (DPBMC - DEEP PURPLISH BLUE)PANEL ASSY 2 (DPBMC - DEEP PURPLISH BLUE)
-
61BN6-W283V-40-P3 PANEL ASSY 2 (MNM3 - MAT GRAY)PANEL ASSY 2 (MNM3 - MAT GRAY)
-
61BN6-W283V-50-P2 PANEL ASSY 2 (BWP1 - BLUISH WHITE)PANEL ASSY 2 (BWP1 - BLUISH WHITE)
-
62BN6-28392-20-00 ...GRAPHIC 2 (DPBMC - DEEP PURPLISH BLUE)...GRAPHIC 2 (DPBMC - DEEP PURPLISH BLUE)
-
63BN6-28392-30-00 ...GRAPHIC 2 (MNM3 - MAT GRAY)...GRAPHIC 2 (MNM3 - MAT GRAY)
-
64BN6-28392-40-00 ...GRAPHIC 2 (BWP1 - BLUISH WHITE)...GRAPHIC 2 (BWP1 - BLUISH WHITE)
-
6590183-05076-00 NUT, SPRINGNUT, SPRING
-
6690111-05045-00 BOLT, HEX. SOCKET BUTTONBOLT, HEX. SOCKET BUTTON
-
6790269-06046-00 RIVETRIVET
-
6890520-30007-00 DAMPER, PLATEDAMPER, PLATE
-
69BN6-28435-00-00 DAMPER 4DAMPER 4
-
70BN6-28229-00-00 COVER 2COVER 2
-
7190111-05045-00 BOLT, HEX. SOCKET BUTTONBOLT, HEX. SOCKET BUTTON
-
72BN6-2836G-00-00 BRACKET 4BRACKET 4
-
7390105-06020-00 BOLT, FLANGEBOLT, FLANGE
-
74BN6-2836K-00-00 PANEL, INNER 1PANEL, INNER 1
-
7590183-05076-00 NUT, SPRINGNUT, SPRING
-
76BN6-2836L-00-00 PANEL, INNER 2PANEL, INNER 2
-
7790269-06008-00 RIVETRIVET
-
78BN6-2836M-00-00 PANEL, INNER 3PANEL, INNER 3
-
7990269-06008-00 RIVETRIVET
-
80BN6-2837L-00-00 PANEL, CONSOLE 1PANEL, CONSOLE 1
-
815SL-84753-00-00 DAMPERDAMPER
-
8290269-06008-00 RIVETRIVET
-
83BN6-2837M-00-00 PANEL, CONSOLE 2PANEL, CONSOLE 2
-
845SL-84753-00-00 DAMPERDAMPER
-
8590269-06008-00 RIVETRIVET
-
86BN6-28357-00-00 STAY 2STAY 2
-
8790111-05003-00 BOLT, HEX. SOCKET BUTTONBOLT, HEX. SOCKET BUTTON
