RACK AND BUMPER для Yamaha WARRIOR YFM350XM CALIFORNIA (3GDV) - 2000 года выпуска
-
№АртикулНазвание
-
13GD-2845N-00-35 BAR, CARRY FRONT (SILVER) (EXCEPT CALIF)BAR, CARRY FRONT (SILVER) (EXCEPT CALIF)
-
14SH-2845N-10-00 BAR, CARRY FRONT (TGM) (CALIF ONLY)BAR, CARRY FRONT (TGM) (CALIF ONLY)
-
21UY-28415-00-00 DAMPER 1DAMPER 1
-
22HR-28415-00-00 DAMPER 1DAMPER 1
-
395827-08012-00 BOLT, FLANGEBOLT, FLANGE
-
43GD-2845R-00-00 BAR, CARRY REARBAR, CARRY REAR
-
43GH-2845R-10-00 BAR, CARRY REARBAR, CARRY REAR
-
595827-08016-00 BOLT, FLANGEBOLT, FLANGE
