GEAR CASE (DRIVE SHAFT) для Tohatsu M30H - 2017 года выпуска`
-
№АртикулНазвание
-
19161E3-0840 BOLT
for Transom "S" Gear CaseBOLT
for Transom "S" Gear Case -
19161E3-0840 BOLT
for Transom "L" Gear CaseBOLT
for Transom "L" Gear Case -
19161E3-0845 BOLT
for Transom "L" Gear CaseBOLT
for Transom "L" Gear Case -
23P0-66233-0 WASHER 8.1-16-1.5
for Transom "S" & "L" Gear CaseWASHER 8.1-16-1.5
for Transom "S" & "L" Gear Case -
33AEQ60000-2 GEAR CASE ASSYGEAR CASE ASSY
-
43AE-60211-0 * ROLLER BEARING 20-27-30* ROLLER BEARING 20-27-30
-
5346-64081-0 SHIM 35-41.9-0.1SHIM 35-41.9-0.1
-
5346-64082-0 SHIM 35-41.9-0.15SHIM 35-41.9-0.15
-
5346-64083-0 SHIM 35-41.9-0.3SHIM 35-41.9-0.3
-
5346-64084-0 SHIM 35-41.9-0.5SHIM 35-41.9-0.5
-
6332-60005-2 PLUG 8-8PLUG 8-8
-
7332-60006-0 GASKET 8.1-15-1GASKET 8.1-15-1
-
83C8-60217-1 TRIM TABTRIM TAB
-
9910103-5620 BOLTBOLT
-
10346-64020-1 BEVEL GEAR BBEVEL GEAR B
-
11346-64027-1 NUTNUT
-
12346-64327-0 DRIVE SHAFT SPRINGDRIVE SHAFT SPRING
-
13346-64328-0 DRIVE SHAFT SPRING GUIDEDRIVE SHAFT SPRING GUIDE
-
14346-64301-5 DRIVE SHAFT (S)
for Transom "S"DRIVE SHAFT (S)
for Transom "S" -
14346-64302-5 DRIVE SHAFT (L)
for Transom "L"DRIVE SHAFT (L)
for Transom "L" -
15346-60213-0 TAPERED ROLLER BEARING 32004TAPERED ROLLER BEARING 32004
-
16369-60206-0 WATER STRAINER
Sub Water StranierWATER STRAINER
Sub Water Stranier -
179218E3-0620 SCREWSCREW
-
18345-65021-0 WATER PUMP IMPELLERWATER PUMP IMPELLER
-
19332-65022-0 KEY 20-4.6-2KEY 20-4.6-2
-
20348-65016-1 PUMP CASE (UPPER)PUMP CASE (UPPER)
-
21348-65011-0 PUMP CASE LINERPUMP CASE LINER
-
223B7-65014-0 WATER PIPE SEAL (LOWER)WATER PIPE SEAL (LOWER)
-
23346-65017-2 PUMP CASE (LOWER)PUMP CASE (LOWER)
-
24346-65013-0 OIL SEAL 17-30-9OIL SEAL 17-30-9
-
25348-65029-1 GUIDE PLATE GASKETGUIDE PLATE GASKET
-
26348-65018-0 PUMP CASE GASKETPUMP CASE GASKET
-
27334-65012-0 DOWEL PIN 4-10DOWEL PIN 4-10
-
28336-62415-0 O-RING 3.5-36O-RING 3.5-36
-
29348-65025-0 WATER PUMP GUIDE PLATEWATER PUMP GUIDE PLATE
-
309101E3-5652 BOLTBOLT
-
31346-66012-1 CAM ROD (S)
for Transom "S"CAM ROD (S)
for Transom "S" -
31346-66013-1 CAM ROD (L)
for Transom "L"CAM ROD (L)
for Transom "L" -
323C8-66011-0 CLUTCH CAMCLUTCH CAM
-
33951407-0312 SPRING PIN 3-12SPRING PIN 3-12
-
343C8-66031-1 CAM ROD BUSHINGCAM ROD BUSHING
-
35332-66021-0 O-RING 2.4-5.8O-RING 2.4-5.8
-
363C8-66032-0 O-RING 3.5-21.7O-RING 3.5-21.7
-
37910103-6612 BOLTBOLT
-
383C8-66308-0 WASHER 6-16-1.5WASHER 6-16-1.5
-
40346-66241-1 SHIFT ROD JOINTSHIFT ROD JOINT
-
41951403-0312 SPRING PIN 3-12
Cam RodSPRING PIN 3-12
Cam Rod -
42346-65100-0 WATER PIPE (S)
for Transom "S" & 25JETWATER PIPE (S)
for Transom "S" & 25JET -
42346-65110-0 WATER PIPE (L)
for Transom "L"WATER PIPE (L)
for Transom "L" -
43346-65203-0 LOCK PLATELOCK PLATE
-
44910103-0610 BOLTBOLT
-
45346-65206-0 WATER PIPE SEAL (UPPER)WATER PIPE SEAL (UPPER)
-
46346-65204-0 WATER PIPE AUXILIARY MOUNT
Water Pipe Lock RubberWATER PIPE AUXILIARY MOUNT
Water Pipe Lock Rubber -
47951403-0312 SPRING PIN 3-12
Shift RodSPRING PIN 3-12
Shift Rod -
48346-60984-0 SUB-WATER INLET HOSE PLUG
OPTSUB-WATER INLET HOSE PLUG
OPT -
493A1-60235-0 WATER STRAINER SETWATER STRAINER SET
-
50930403-0400 * NYLON NUT 4-P0.7* NYLON NUT 4-P0.7
-
519215E3-0430 * SCREW* SCREW
