DRIVE SHAFT HOUSING для Tohatsu M30H - 2017 года выпуска`
-
№АртикулНазвание
-
1346Q61191-3 DRIVE SHAFT HOUSING (S)
for Transom "S" & 25JETDRIVE SHAFT HOUSING (S)
for Transom "S" & 25JET -
1346Q61192-3 DRIVE SHAFT HOUSING (L)
for Transom "L"DRIVE SHAFT HOUSING (L)
for Transom "L" -
2346-67116-0 ENGINE BASEMENT SEAL L=630ENGINE BASEMENT SEAL L=630
-
39101E3-5840 BOLTBOLT
-
49106E3-0808 BOLTBOLT
-
5332-60006-0 GASKET 8.1-15-1GASKET 8.1-15-1
-
6345-01111-0 DOWEL PIN 6-12DOWEL PIN 6-12
-
9346-66226-0 GROMMET 17-5.5GROMMET 17-5.5
Все узлы модели:
- CYLINDER CRANK CASE
- PISTON CRANK SHAFT
- INTAKE MAINFOLD FUEL PUMP
- CARBURETOR
- RECOIL STARTER
- MAGNETO
- ELECTRIC PARTS
- ELECTRIC PARTS (F TYPE)
- • DRIVE SHAFT HOUSING
- GEAR CASE (DRIVE SHAFT)
- GEAR CASE (PROPELLER SHAFT)
- BRACKET
- TILLER HANDLE
- BOTTOM COWL
- SHIFT
- REMOTE CONTROL PARTS
- TOP COWL
- FUEL TANK
- COMPONENT PARTS OF REMOTE CONTROL
- COMPONENT PARTS OF REMOTE CONTROL (ELECTRIC PARTS)
- OPTIONAL PARTS (1)
- OPTIONAL PARTS (2)
- ASSEMBLY KIT PARTS
