PISTON CRANK SHAFT для Tohatsu 25JET - 2012 года выпуска`
-
№АртикулНазвание
-
13P1-00069-1 CRANKSHAFT SUB-ASSY
for M25/30H & 25JETCRANKSHAFT SUB-ASSY
for M25/30H & 25JET -
23P1-00031-0 * CRANKSHAFT A* CRANKSHAFT A
-
3346-00032-0 * CRANKSHAFT B* CRANKSHAFT B
-
4346-00033-0 * CRANKSHAFT C* CRANKSHAFT C
-
5346-00034-0 * CRANKSHAFT D* CRANKSHAFT D
-
6334-00061-1 * CRANK PIN* CRANK PIN
-
73J2-00114-0 * MAIN BEARING 6305
Center* MAIN BEARING 6305
Center -
8346-00051-1 * LABYRINTH PACKING* LABYRINTH PACKING
-
9951407-0308 * SPRING PIN 3-8* SPRING PIN 3-8
-
10336-00040-1 * CONNECTING ROD
for M25/30H & 25JET* CONNECTING ROD
for M25/30H & 25JET -
11356-00043-0 * ROLLER BEARING 20-28-18* ROLLER BEARING 20-28-18
-
12345-00113-0 MAIN BEARING 5206
UpperMAIN BEARING 5206
Upper -
133J2-00114-0 MAIN BEARING 6305
LowerMAIN BEARING 6305
Lower -
14332-00143-0 SHIMSHIM
-
15346-00116-0 SPACER 25.2-34-1.6SPACER 25.2-34-1.6
-
16945107-2500 C-RINGC-RING
-
17346-00001-3 PISTON
for M25/30H & 25JET STDPISTON
for M25/30H & 25JET STD -
17346-00004-3 PISTON (0.5 O/S)
for M25/30H & 25JET OPTPISTON (0.5 O/S)
for M25/30H & 25JET OPT -
19345-00042-0 ROLLER BEARING 17-21-27
for M25/30H & 25JETROLLER BEARING 17-21-27
for M25/30H & 25JET -
203C8-00021-1 PISTON PIN
for M25/30H & 25JETPISTON PIN
for M25/30H & 25JET -
22334-00024-1 PISTON PIN CLIP
for M25/30H & 25JETPISTON PIN CLIP
for M25/30H & 25JET -
25346-00115-0 THRUST PLATETHRUST PLATE
-
26346-00122-0 OIL SEAL 24-40-8OIL SEAL 24-40-8
-
273MV-87123-0 PISTON RING SET
for M25/30H & 25JET STDPISTON RING SET
for M25/30H & 25JET STD -
273MV-87124-0 PISTON RING SET (0.5 O/S)
for M25/30H & 25JET OPTPISTON RING SET (0.5 O/S)
for M25/30H & 25JET OPT -
28346-00011-0 * PISTON RING
for M25/30H & 25JET STD 1st, 2nd* PISTON RING
for M25/30H & 25JET STD 1st, 2nd -
28346-00014-0 * PISTON RING (0.5 O/S)
for M25/30H & 25JET OPT 1st, 2nd* PISTON RING (0.5 O/S)
for M25/30H & 25JET OPT 1st, 2nd
