GEAR CASE для Tohatsu M9.8B - 2011 года выпуска`

№

Артикул

Название
1

3B2Q60000-2 Gear Case Ass'y"

Gear Case Ass'y"

29 740 ₽
2

3B2-60211-0 * Roller Bearing 15-21-16"

* Roller Bearing 15-21-16"

2 720 ₽
3

9601-0-6204 Ball Bearing 6204"

Ball Bearing 6204"

2 080 ₽
4

9161E3-0635 Bolt"

Bolt"

270 ₽
5

9401E3-0600 Washer"

Washer"

120 ₽
6

332-60005-2 Plug"

Plug"

1 050 ₽
7

332-60006-0 Gasket 8.1-15-1"

Gasket 8.1-15-1"

200 ₽
8

3V1-60217-0 Trim Tab"

Trim Tab"

1 450 ₽
9

910103-5620 Bolt"

Bolt"

170 ₽
10

3AA-60206-0 Water Strainer W=17"
Mark “A”

Water Strainer W=17"
Mark “A”

670 ₽
11

921503-0430 Screw"

Screw"

120 ₽
12

930403-0400 Nylon Nut 4-P0.7"

Nylon Nut 4-P0.7"

210 ₽
13

3B2Q60100-0 Propeller Shaft Housing Ass'y"

Propeller Shaft Housing Ass'y"

5 380 ₽
14

345-65015-0 * O-Ring 3.2-47"

* O-Ring 3.2-47"

360 ₽
15

369-60111-0 * Oil Seal 15-28-10"

* Oil Seal 15-28-10"

1 230 ₽
16

9601-0-6004 * Ball Bearing 6004"

* Ball Bearing 6004"

2 440 ₽
17

9101E3-5620 Bolt"

Bolt"

360 ₽
18

3B2-64010-0 Bevel Gear Ass'y (A)

Bevel Gear Ass'y (A)

9 540 ₽
19

3B2-64020-0 Bevel Gear B"

Bevel Gear B"

2 130 ₽
20

3B2-64030-0 Bevel Gear C"

Bevel Gear C"

9 270 ₽
21

369-64032-0 Washer 15.2-19-1.9"

Washer 15.2-19-1.9"

630 ₽
22

369-64014-0 Shim 21-28-0.1"

Shim 21-28-0.1"

660 ₽
22

369-64015-0 Shim 21-28-0.15"

Shim 21-28-0.15"

660 ₽
23

3V1-64211-0 Propeller Shaft"

Propeller Shaft"

11 420 ₽
24

3B2-64215-0 Clutch"

Clutch"

6 070 ₽
25

301-64217-0 Pin 3.5-28"

Pin 3.5-28"

260 ₽
26

3V1-64221-0 Spring"

Spring"

540 ₽
27

369-64223-0 Push Rod"

Push Rod"

1 220 ₽
28

3B2-64222-0 Spring Retainer"

Spring Retainer"

750 ₽
29

3B2-65021-1 Water Pump Impeller"

Water Pump Impeller"

3 080 ₽
30

3B2-65022-0 Key"

Key"

560 ₽
31

3B2-65016-0 Pump Case (Upper)

Pump Case (Upper)

3 500 ₽
32

3B2-65011-0 Pump Case Liner"

Pump Case Liner"

1 290 ₽
33

331-65014-0 Water Pipe Seal (Lower)

Water Pipe Seal (Lower)

320 ₽
34

3B2-65018-1 Pump Case Gasket"

Pump Case Gasket"

370 ₽
35

3B2-65025-0 Water Pump Guide Plate"

Water Pump Guide Plate"

570 ₽
36

3B2-65029-1 Guide Plate Gasket"

Guide Plate Gasket"

370 ₽
37

9161E3-0650 Bolt"

Bolt"

210 ₽
38

940103-0600 Washer"

Washer"

110 ₽
39

3V1-65017-0 Pump Case (Lower)

Pump Case (Lower)

4 370 ₽
40

309-60111-0 Oil Seal 12-24-8"

Oil Seal 12-24-8"

1 010 ₽
41

3B2-65020-0 Pump Case Gasket (Lower)

Pump Case Gasket (Lower)

720 ₽
42

3B2-64081-0 Shim 28-36.8-0.1"

Shim 28-36.8-0.1"

740 ₽
42

3B2-64082-0 Shim 28-36.8-0.15"

Shim 28-36.8-0.15"

740 ₽
42

3B2-64083-0 Shim 28-36.8-0.3"

Shim 28-36.8-0.3"

290 ₽
43

3B2-64306-1 Drive Shaft Ass'y (S)
for Transom “S”

Drive Shaft Ass'y (S)
for Transom “S”

16 540 ₽
43

3B2-64307-1 Drive Shaft Ass'y (L)
for Transom “L”

Drive Shaft Ass'y (L)
for Transom “L”

10 110 ₽
43

3B2-64309-1 Drive Shaft Ass'y (UL)
for Transom “UL”

Drive Shaft Ass'y (UL)
for Transom “UL”

11 060 ₽
44

9601-0-6301 * Ball Bearing 6301"

* Ball Bearing 6301"

2 000 ₽
45

369-66011-0 Clutch Cam"

Clutch Cam"

2 380 ₽
46

951403-0310 Spring Pin 3-10"

Spring Pin 3-10"

120 ₽
47

3B2-66012-0 Cam Rod (S)
for Transom “S”

Cam Rod (S)
for Transom “S”

1 560 ₽
47

3B2-66013-0 Cam Rod (L)
for Transom “L”

Cam Rod (L)
for Transom “L”

1 860 ₽
47

3B2-66014-0 Cam Rod (UL)
for Transom “UL”

Cam Rod (UL)
for Transom “UL”

1 990 ₽
48

369-66031-0 Cam Rod Bushing"

Cam Rod Bushing"

1 220 ₽
49

369-66021-1 O-Ring 2.5-4.9"

O-Ring 2.5-4.9"

320 ₽
50

332-66032-0 O-Ring 2.4-15.4"

O-Ring 2.4-15.4"

320 ₽
51

369-66033-0 Stopper"

Stopper"

360 ₽
52

910103-5625 Bolt"

Bolt"

170 ₽
53

3B2-65100-0 Water Pipe (S)
for Transom “S”

Water Pipe (S)
for Transom “S”

1 290 ₽
53

3B2-65110-0 Water Pipe (L) "
for Transom “L”

Water Pipe (L) "
for Transom “L”

1 440 ₽
53

3B2-65120-0 Water Pipe (UL)
for Transom “UL”

Water Pipe (UL)
for Transom “UL”

1 700 ₽
54

3B2-65195-0 Grommet

Grommet

170 ₽
55

3B2B64515-1 Propeller Ass'y (7.5")
M9.8B “L”, “UL” STD 3*216*190

Propeller Ass'y (7.5")
M9.8B “L”, “UL” STD 3*216*190

25 770 ₽
55

3B2B64517-1 Propeller Ass'y (8.5")
M9.8B/8B/6B “S” STD 3*226*211

Propeller Ass'y (8.5")
M9.8B/8B/6B “S” STD 3*226*211

9 930 ₽
55

3B2B64514-1 Propeller Ass'y (7")
M8B/6B “L”, “UL” STD 3*226*178

Propeller Ass'y (7")
M8B/6B “L”, “UL” STD 3*226*178

25 770 ₽
55

3B2B64513-1 Propeller Ass'y (6.5")
OPT 3*216*165

Propeller Ass'y (6.5")
OPT 3*216*165

25 770 ₽
55

3B2B64519-1 Propeller Ass'y (9.5")
OPT 3*226*255

Propeller Ass'y (9.5")
OPT 3*226*255

9 990 ₽
56

3B2-64230-1 Thrust Holder Ass'y

Thrust Holder Ass'y

1 060 ₽
57

369-64124-0 Washer 10.5-28-2

Washer 10.5-28-2

840 ₽
58

369-64121-0 Propeller Nut

Propeller Nut

1 230 ₽
59

951503-0318 Split Pin 3-18

Split Pin 3-18

240 ₽
