OPTIONAL PARTS ACCESSORIES для Tohatsu M6B - 2011 года выпуска
-
№АртикулНазвание
-
1312-72201-0 Safety Rope ?4-1000Safety Rope ?4-1000
-
2369-72100-0 Tool KitTool Kit
-
3346-76160-2 Rectifier KitRectifier Kit
-
43B2-06128-0 Alternator Kit 12V80W
for MFAlternator Kit 12V80W
for MF -
5921521-6625 * Screw* Screw
-
6369-76167-0 Extension Cord (Light) L=2000Extension Cord (Light) L=2000
-
73B7-72530-2 Tachometer Ass'yTachometer Ass'y
-
83B7-72659-0 * Meter Bulb 12V-1.8W* Meter Bulb 12V-1.8W
-
93B7-72656-0 * Meter Damper* Meter Damper
-
103B7-72661-0 * Fitting Plate* Fitting Plate
-
11930103-0500 * Nut* Nut
-
12941303-0500 * Spring Washer* Spring Washer
-
13361-72539-0 Tachometer Lead Wire L=6000Tachometer Lead Wire L=6000
-
14345-67169-0 GrommetGrommet
-
15361-72543-0 Separate Cord
YellowSeparate Cord
Yellow -
16361-72542-0 Separate Cord
WhiteSeparate Cord
White -
173B2B05180-0 Vertical Starter KitVertical Starter Kit
-
183B2B05911-0 * Vertical Starter Guide* Vertical Starter Guide
-
199101F4-0654 * Bolt* Bolt
-
20940103-0600 * Washer* Washer
-
21930103-0600 * Nut* Nut
-
223B2-05912-0 * Seal* Seal
-
233B2-64110-1 Test Propeller Ass'yTest Propeller Ass'y
-
26336-60007-0 Flushing Plug
OPTFlushing Plug
OPT -
273B2B63037-0 Long Handle L=400Long Handle L=400
-
283F3-72540-0 Spark Tester PET-4000Spark Tester PET-4000
-
293C7-72301-0 Engine Oil 0.4LEngine Oil 0.4L
-
293C7-72302-0 Engine Oil 1LEngine Oil 1L
-
293C7-72304-0 Engine Oil 4LEngine Oil 4L
-
293C7-72303-0 Engine Oil 20LEngine Oil 20L
-
30332-72306-0 Gear Oil 500mLGear Oil 500mL
-
313AC-72326-0 Touch-Up Paint
Aqua MarineTouch-Up Paint
Aqua Marine
Все узлы модели:
- ASSEMBLY KIT PARTS
- BOTTOM COWL
- BRACKET REVERSE LOCK
- CARBURETOR FUEL PUMP
- COMPONENT PARTS OF REMOTE CONTROL BOX
- COMPONENT PARTS OF REMOTE CONTROL BOX (ELECTRIC PARTS)
- CYLINDER CRANK CASE
- DRIVE SHAFT HOUSING
- FUEL TANK
- GEAR CASE
- INTAKE MAINFOLD REED VALVE THROTTLE
- MAGNETO ELECTRIC PARTS
- • OPTIONAL PARTS ACCESSORIES
- PISTON CRANKSHAFT
- RECOIL STARTER STARTER LOCK
- REMOTE CONTROL
- SHIFT
- TILLER HANDLE
- TOP COWL
