Gear case (drive shaft & water pump) для Tohatsu MFS9.9A - 2002 года выпуска`
-
№АртикулНазвание
-
13V3S60000-0 Кожух шестерниКожух шестерни
-
23V3-60014-0 Bushing, gear housingBushing, gear housing
-
33V3-60005-0 Drain screrwDrain screrw
-
43V3-60006-0 Шайба уплотнительнаяШайба уплотнительная
-
53V3-64328-0 Sleeve ass'ySleeve ass'y
-
63V3-60238-0 BushingBushing
-
73V3-60213-0 BushingBushing
-
83V3-60236-0 Screw plug kitScrew plug kit
-
93V3-60006-0 Шайба уплотнительнаяШайба уплотнительная
-
103V3-60206-0 ScreenScreen
-
113V3-60205-0 Screw(0.25x0.875)Screw(0.25x0.875)
-
123V3-64218-0 AnodeAnode
-
143V3-65036-0 ВаликВалик
-
153V3-64020-0 Pinion gear(13-26)Pinion gear(13-26)
-
163V3-64021-0 Thrust washerThrust washer
-
173V3-60211-0 BearingBearing
-
183V3-65017-0 Water pump baseWater pump base
-
193V3-65020-0 O-RingO-Ring
-
203V3-65039-0 ВаликВалик
-
213V3-65201-0 RetainerRetainer
-
223V3-65202-0 Screw(#10x0.875)Screw(#10x0.875)
-
233V3-66031-0 Quad ringQuad ring
-
243V3-60223-0 Oil SealOil Seal
-
253V3-64084-0 O-RingO-Ring
-
263V3-65035-0 Водная трубаВодная труба
-
273V3-65025-0 Face plateFace plate
-
283V3-65016-0 Cover ass'yCover ass'y
-
293V3-65011-0 Insert
NSSInsert
NSS -
303V3-65014-0 ВаликВалик
-
313V3-65021-0 ИмпеллерИмпеллер
-
323V3-65022-0 Key ass'yKey ass'y
-
333V3-65023-0 Washer
NSSWasher
NSS -
343V3-65205-0 GuideGuide
-
35910103-0630 BoltBolt
-
9101E3-0630 BoltBolt
-
36940103-0600 WasherWasher
-
373V3-66011-0 Cam-shiftCam-shift
-
383V3-66012-0 Shift Shaft
ShortShift Shaft
Short -
383V3-66013-0 Shift Shaft
LongShift Shaft
Long -
39930203-0600 NutNut
-
403V3-66241-0 СоединительСоединитель
-
413V3-66213-0 Shift shaft(upper)Shift shaft(upper)
-
42945303-0600 E-RingE-Ring
-
433V3-64301-0 Drive Shaft S
ShortDrive Shaft S
Short -
433V3-64302-0 Drive shaft l
LongDrive shaft l
Long -
443V3-64334-0 Thrust washerThrust washer
