Fuel tank (remote) для Tohatsu M5B - 2002 года выпуска

  • №
    Артикул
    Название
  • 1
    3B3-70102-0 Fuel tank assy
    Not Interchangeable, 44001-
    Fuel tank assy
    Not Interchangeable, 44001-
  • 1
    9812-7-1000 Fuel pipe
    D7-D12-1000MM, -44000
    Fuel pipe
    D7-D12-1000MM, -44000
  • 1
    369-70056-0 Fuel tank complete
    Not for Sale
    Fuel tank complete
    Not for Sale
  • 1
    98AB-7-1000 Rubber pipe
    Interchangeable with Older and Newer Parts, 44001-
    Rubber pipe
    Interchangeable with Older and Newer Parts, 44001-
  • 2
    3B7-70200-1 Primer bulb assy
    Not Interchangeable, 44001-
    Primer bulb assy
    Not Interchangeable, 44001-
  • 2
    334-70020-0 Fuel tank cap ass'y
    Fuel tank cap ass'y
  • 2
    332-70204-0 Clip
    -44000
    Clip
    -44000
  • 2
    345-70200-0 Primer bulb assy
    -44000
    Primer bulb assy
    -44000
  • 3
    345-70260-0 Fuel connector b
    -64250
    Fuel connector b
    -64250
  • 3
    3B2-70260-1 New part
    Interchangeable with Older and Newer Parts, 64251-
    New part
    Interchangeable with Older and Newer Parts, 64251-
  • 3
    334-70021-0 Gasket fuel tank cap
    Gasket fuel tank cap
  • 3
    9812-7-1300 Fuel pipe b
    D7-D12-1300MM, -44000
    Fuel pipe b
    D7-D12-1300MM, -44000
  • 3
    98AB-7-1300 Fuel pipe b
    Interchangeable with Older and Newer Parts, 44001-
    Fuel pipe b
    Interchangeable with Older and Newer Parts, 44001-
  • 4
    332-70201-0 Clamp
    -44000
    Clamp
    -44000
  • 4
    369-70263-0 Bushing fuel connector
    Bushing fuel connector
  • 4
    337-70120-0 Fuel gauge (with float)
    Fuel gauge (with float)
  • 5
    941303-0500 Spring Washer
    Spring Washer
  • 5
    334-70121-0 Bracket fuel gauge
    Bracket fuel gauge
  • 6
    921-51051-0 Screw, throttle lever
    Screw, throttle lever
  • 6
    332-70217-0 Clamp, primer bulb
    Clamp, primer bulb
  • 6
    9810-5-0150 Fuel pipe 5mm (1 ea.=1 meter)
    D5-D10-150MM
    Fuel pipe 5mm (1 ea.=1 meter)
    D5-D10-150MM
  • 98AB-501000 Fuel pipe 5mm (1 ea.=1 meter)
    Fuel pipe 5mm (1 ea.=1 meter)
  • 7
    345-70212-0 Connector a primer bulb
    Connector a primer bulb
  • 7
    369-02230-0 Фильтр топливный
    Фильтр топливный
  • 8
    338-02215-0 Clip
    Clip
  • 8
    334-70123-1 O-Ring
    O-Ring
  • 8
    345-70213-0 Connector b primer bulb
    Connector b primer bulb
  • 9
    9810-5-0200 Fuel pipe
    D5-D10-200MM
    Fuel pipe
    D5-D10-200MM
  • 9
    345-70127-1 Housing fuel gauge
    -44000
    Housing fuel gauge
    -44000
  • 9
    3B7-70127-0 Housing, fuel gauge assy
    Not Interchangeable, 44001-
    Housing, fuel gauge assy
    Not Interchangeable, 44001-
  • 9
    345-70250-0 Fuel connector a
    -64250
    Fuel connector a
    -64250
  • 9
    3B2-70250-1 New part
    Interchangeable with Older and Newer Parts, 64251-
    New part
    Interchangeable with Older and Newer Parts, 64251-
  • 10
    309-06972-0 Clamp,6.5-47.5P
    Clamp,6.5-47.5P
  • 10
    3B2-70281-0 New part
    44001-64250
    New part
    44001-64250
  • 11
    922-23052-0 Screw
    Screw
  • 12
    930103-0500 Nut
    Nut
  • 12
    334-70128-0 Gasket 5.1-12-0.8
    Gasket 5.1-12-0.8
  • 13
    9812-7-0156 Fuel suction pipe
    D7-D12-156MM, -44000
    Fuel suction pipe
    D7-D12-156MM, -44000
  • 13
    98AB-7-0146 Fuel suction pipe
    Not Interchangeable, 44001-
    Fuel suction pipe
    Not Interchangeable, 44001-
  • 14
    345-70114-0 Clip
    Clip
  • 18
    332-70214-0 Nylon ball (1/4)"
    Nylon ball (1/4)"
  • 19
    951-43022-0 Spring Pin
    -44000
    Spring Pin
    -44000
  • 21
    336-70112-0 Gasket 10.2-16-0.5
    44001-
    Gasket 10.2-16-0.5
    44001-
