AIR INTAKE PIPE (CANADA) для Suzuki GSX-R1000RZ - 2017 года выпуска

  • №
    Артикул
    Название
  • 1
    94420-17K00 PIPE, AIR INTAKE (RH)
    PIPE, AIR INTAKE (RH)
  • 2
    63115-37H00 ...CUSHION, INTAKE PIPE NO.2
    ...CUSHION, INTAKE PIPE NO.2
  • 3
    36930-60A10 ...CUSHION, INATAKE PIPE
    ...CUSHION, INATAKE PIPE
  • 4
    94430-17K00 PIPE, AIR INTAKE (LH)
    PIPE, AIR INTAKE (LH)
  • 5
    63115-37H00 ...CUSHION, INTAKE PIPE NO.2
    ...CUSHION, INTAKE PIPE NO.2
  • 6
    36930-60A10 ...CUSHION, INATAKE PIPE
    ...CUSHION, INATAKE PIPE
  • 7
    09148-05052 NUT
    NUT
  • 8
    09320-08028 CUSHION
    CUSHION
  • 9
    09111-06106 BOLT (6X12)
    BOLT (6X12)
  • 10
    94600-17K00-YVB COVER, INTAKE (YVB - BLACK)
    COVER, INTAKE (YVB - BLACK)
  • 11
    68270-17K10-BKQ ...TAPE SET, INTAKE COVER (BKQ - BLACK/BLUE/BLUE)
    ...TAPE SET, INTAKE COVER (BKQ - BLACK/BLUE/BLUE)
  • 12
    94670-17K20-YVB COVER, INTAKE (RH) (YVB - BLACK)
    COVER, INTAKE (RH) (YVB - BLACK)
  • 13
    68275-17K20-BKN ...TAPE, INTAKE COVER (RH) (BKN - BLACK/ORANGE/SILVER/BLACK)
    ...TAPE, INTAKE COVER (RH) (BKN - BLACK/ORANGE/SILVER/BLACK)
  • 14
    73415-70A00 ...CUSHION
    ...CUSHION
  • 15
    94680-17K20-YVB COVER, INTAKE (LH) (YVB - BLACK)
    COVER, INTAKE (LH) (YVB - BLACK)
  • 16
    68276-17K20-BKN ...TAPE, INTAKE COVER (LH) (BKN - BLACK/ORANGE/SILVER/BLACK)
    ...TAPE, INTAKE COVER (LH) (BKN - BLACK/ORANGE/SILVER/BLACK)
  • 17
    73415-70A00 ...CUSHION
    ...CUSHION
  • 18
    09132-05050 SCREW (5X12)
    SCREW (5X12)
  • 19
    36930-82010 CUSHION, COVER INTAKE NO.1
    CUSHION, COVER INTAKE NO.1
  • 20
    94476-38C00 CUSHION, COVER INTAKE CTR (CUT AS REQUIRED)
    CUSHION, COVER INTAKE CTR (CUT AS REQUIRED)
  • 21
    94633-31J00 CUSHION, COVER SIDE
    CUSHION, COVER SIDE
  • 22
    09321-06013 CUSHION
    CUSHION
  • 23
    09409-06314 CLIP
    CLIP
