WHEEL - FRONT для Suzuki GSX-1300R L4 - 2014 года выпуска

  • №
    Артикул
    Название
  • 1
    54111-15H10-019 WHEEL, FRONT (17M/CXMT3.50) (BLACK)
    WHEEL, FRONT (17M/CXMT3.50) (BLACK)
  • 2
    54731-33E20 SPACER, HUB BEARING
    SPACER, HUB BEARING
  • 3
    09262-25167 BEARING (25X52X15)
    BEARING (25X52X15)
  • 4
    09285-32004 OIL SEAL (32X52X7)
    OIL SEAL (32X52X7)
  • 5
    54162-27G00 RING, SPEED SENSOR FR (50T)
    RING, SPEED SENSOR FR (50T)
  • 6
    07130-0512A BOLT
    BOLT
  • 7
    54711-15H00 AXLE, FRONT
    AXLE, FRONT
  • 8
    54712-41G10 BOLT, FRONT AXLE
    BOLT, FRONT AXLE
  • 9
    54751-41G10 SPACER, FRONT AXLE, RIGHT HAND
    SPACER, FRONT AXLE, RIGHT HAND
  • 10
    59210-15H10 DISC, FRONT BRAKE
    DISC, FRONT BRAKE
  • 11
    09106-08160 BOLT (8X21)
    BOLT (8X21)
  • 12
    55110-24F60 TIRE, FRONT (120/70ZR17M/C (58W))
    TIRE, FRONT (120/70ZR17M/C (58W))
  • 13
    43130-24A00 VALVE ASSY, WHEEL RIM (TR412)
    VALVE ASSY, WHEEL RIM (TR412)
  • 14
    55411-22H00 BALANCER, WHEEL NO.1 (10G)
    BALANCER, WHEEL NO.1 (10G)
  • 14
    55412-22H00 BALANCER, WHEEL NO.2 (20G)
    BALANCER, WHEEL NO.2 (20G)
  • 14
    55413-22H00 BALANCER, WHEEL NO.3 (30G)
    BALANCER, WHEEL NO.3 (30G)
